Home > Products > 24V Power Adapters > d-sub cable adapter 24v 2A 48W with UL/CUL CE GS KC CB SAA FCC
d-sub cable adapter 24v 2A 48W with UL/CUL CE GS KC CB SAA FCC
- 100 Case / Cases per Month
- Shekou Port Shenzhen
- Credit Card PayPal
Product Details
Place of Origin: | Guangdong, China | Brand Name: | ZH | Model Number: | ZF120A-2402000 |
Output Type: | DC | Connection: | Desktop |
Product Description
Specifications
d-sub cable adapter 24v 2A 48W with UL/CUL CE GS KC CB1.Safety certification
2.10 Years Experience Factory
d-sub cable adapter 24v 2A 48W
Advantages
1. input voltage: AC 100-240V 50/60HZ
2. range voltage: AC 86-264V 47/63HZ
3. High efficiency and low operation temperature
4. AC input power suitable for the world
5. Soft-start current can reduce the AC input impact efficiency
6. With short-circuit and overload protection
7. Compact size ,light weight
8. 100%full-load burning test
9. Installed with EMI filter ,minimum wave
SAFETY & LEAD-FREE: UL/CUL CE GS KC CB SAA FCC 3C ROHS PSE
d-sub cable adapter 24v 2A 48W Spec. as following:
Input Rated Voltage : | 86Vac~264Vac |
Input Frequency Range: | 47Hz~63Hz |
Input Inrush Current : | 0.3A max |
Efficiency : | 85%(MIN)at Rated Voltage |
Output: | 24V 2A |
Output power : | 48W |
Ripple and Noise : | <120Mv at full road with 20MHz bandwidth |
Turn On Delay Time: | <3S (AC:110V and full load) |
Safety protection : | over voltage and current protection for ac dc adapter |
Leakage Current: | <5mA |
DC cable length: | 1.5 meters |
Operating Temperature: | 0°C----+60°C |
Storage Temperature: | -20°C----+85°C |
Certificate: | UL/CUL CE GS KC CB SAA FCC 3C ROHS PSE |
Safety Standard : | EN60950-1 UL60950-1 ESD (EN61000 3-3) |
Application: | can fit UK US Euroepan market ,and can been used by Bluetooth device ,CCTV camera ,and LCD minitor , mobile phone ,pos machine ,laptop ac adapter and so on . |
1.Application range
You can choose below DC connector
Power Adapter dc Connector (on request):
2.Production Process
1.Purchasing the materials: each of our materials must be tested before
3.Tinning:Retouching-Testing,to make each products quality best.
4.Assembling:each little parts need to assemble by man-made and need to test.
5.Aging:To test the products working life and make each product can be used
as possible as long time.
6. Product outbound and package
7.Certificates
Amost all of our products get UL/CUL CE GS KC CB SAA FCC 3C ROHS PSE
etc certificates,and if you have Special requirements of certificates,we can help to apply
for you.
8.Product Shipment terms
About the shipment terms,except below terms,we also can send the products
as your requirements,such as by sea
9. Our international customers
10.Our working environment
Shenzhen Zhen Huan Electronic Co., Ltd. is an excellent power solution provider, with more
than 10 years' experience in R & D and production of power supplies. We are committed to
provide the highest quality products and services with the best prices and the most punc-
tual delivery time.
Our products are 100% through high temperature ageing, which accords with CCC, CE, UL
and many other authoritative organization security authentication standard. In order to
ensure timely delivery, we always keep standard product inventory. If you can't find the
right type from our product display or you can't find the right product in the market, please
contact us, we will develop satisfactory customized products for you.
We always adhere to the corporate value of "excellent quality and high efficient service"
to provide you the best service.
11.Feedback
I am Frank. If you take interest, pls contact me now!
Skype:zhpower19 Cellphone/QQ: 1533 8365 868
