Pneumatic Penetrating Type Knife Gate Valve
US$ 1 - 500
MOQ: 1 Piece
Key Specifications
Get Latest Price
Standard or Nonstandard:
Standard
Structure:
Gate
Pressure:
Low Pressure
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Nongbi Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
DN200 PN10 Pneumatic Knife Gate Valve for Paper MillUS$ 1 - 500MOQ: 1 Piece -
For Paper Mill MINI Electric Segment Regulating Ball ValveUS$ 1 - 500MOQ: 1 Piece
-
8 Inch Gate Valve Pneumatic Crossing Knife Gate ValveUS$ 1 - 500MOQ: 1 Piece
-
Stainless Steel Pneumatic Steam Cutting O-Type Control Ball ValveUS$ 1 - 500MOQ: 1 Piece
-
Pneumatic v Port Ball Valve, Spring Return Ball Valve, Control Ball ValvesUS$ 1 - 500MOQ: 1 Piece
Standard or Nonstandard
Standard
Structure
Gate
Pressure
Low Pressure
Power
Pneumatic
Material
Stainless Steel
Temperature of Media
Normal Temperature
Media
Oil
Port Size
DN80-DN400
Place of Origin
Zhejiang, China
Model Number
PSLDSA-200
Brand Name
Lageci
Application
General
|
|
Pneumatic Penetrating type Knife Gate Valve
Nominal Pressure Rating:1.0 Mpa Working Temperature:-20~150℃ Nominal Diameter:DN80-400mm Main Material:Valve Body 304,316,316L Valve Plug 304,316,316L Leakage:GB/T4213-2008IV Control voltagel:1.24VDC 2.220VAC Position limit switch voltage:1.24VDC 2.220VAC Air Supply Pressure:0.4-0.6Mpa Accessories: 1.Solenoid valve 2.Air Filter 3. Position limit switch Box 4.Flange
|
|
|
|
|
|
|
|
|
|
|
|
|
