LED down light detail information :
| Item NO | led down light |
| Certification | CE RoHS |
| IP | IP20 |
| LED | SMD2835,0.2W/PCS |
| Watts | 5W/7W/9W/12W/15W/18 |
| Housing | Die-casting Aluminum |
| Driver | With External MeanWell driver |
| Power Factor | 0.95-0.98 |
| CRI | >80 Ra |
| Lumen | 500-1700 LM |
| CCT | Warm White:2800-3200K/Natural white:4000-4500K/Pure white 5500-6500K |
| Beamangle | NO |
| Material | Die-casting Aluminum + PC cover |
| Warranty | three years |
| Usage | hotel, comercial led lighting |
| WorkingTemperature: | -20°C-45°C |
| Lifespan time | 50000 hours |
led down light SMD2835 advantage:
1.With External Constant Current Power Supply.
2.Use the most mature international well-known LED SMD2835 as the light source,
3.Use the high quality aluminum PCB for LED’s better heat dissipation.
4 High-grade PC cover with nice light transmittance (>95%).
5.90º beam angle makes the lighting effect better.
6. Ambient temperature:-20℃~40℃, surface temperature: 42℃~45℃.
7. No mercury, lead or other hazardous materials; no radiation, no electromagnetic radiation, no frequency flash, instant startup, no hurting eyes.
Power |
Size |
Cut out |
Luminous Flux |
Power Supply |
5W |
Φ90*H50mm |
Φ78mm |
320-380LM |
Input:AC85-265V Output:DC30-42V/500mA |
7W |
Φ109*H48mm |
Φ96mm |
500-550LM |
Input:AC85-265V Output:DC30-42V/750mA |
| 9W | Φ139*H50mm | Φ120mm | 650-700LM |
Input:AC85-265V Output:DC30-42V/500mA |
| 12W | Φ139*H50mm | Φ120mm | 800-900LM |
Input:AC85-265V Output:DC30-42V/500mA |
15W |
Φ162*H52mm |
Φ145mm |
1000-1100LM |
Input:AC85-265V
Output:DC30-42V/500mA |
18W |
Φ181*H45mm |
Φ165mm |
1000-1100LM |
Input:AC85-265V Output:DC30-42V/950mA |
led flood light Application:
Widely used in Hotels, Conference, Meeting rooms, Commercial Purposes, Supermarket and other indoor lights applications.
Kingstar established in 2005, and started to produce the LED tube lights from 2007, have ISO, CE, RoHS, EMC, LVD, TUV,ERP, SAA, Ctick, ETL, UL and DLC sertificates.
The production capacity is about 120-150K pcs per month so far, 12-15 days for under 5000pcs bulk order delivery .
Coco Cola, Ikea, Maxiam, SINOPEC, Toyota,Lexus, Bridgestone, etc. are our cooperation business partners.
Kingstar is one of the OEM factories for NVC-- No. One Lighting Brand in China.
OEM, ODM are available.
DHL/UPS/TNT/Fedex account for delivery
Container shipping can be available
Q1: What is the Warranty for the tube light?
A1: For the tube light, we have 3 years warranty. And some special offer with 5 years warranty as customers request.
Q2: What is colour temperature?
A2: King Star's LED Lighting offer ceilling lights in warm, natural, pure and cool white with colour temperatures measured in Kelvin (K). The lower the colour temperature is,the warmer the light given by the LED:
- Warm white = 2700K-3200K
- Natural white = 4000K-4500K
- Pure white = 5000K-5500K
- Cool white = 6000K-6500K
Q3:: What is CRI?
A3: CRI is a figure which feedback the real objects colors. Higher CRI with higher cost. For LED tubes, the CRI is higher than 80. For the outdoor light, the CRI higher than 70 is OK at most of applications.
Q4: What is the AC Voltage tolerance for our LED tubes?
A4: Their AC voltage tolerance is +/- 10%.
Q5: Is there cheap shipping cost to import to our country?
A5: For small order, express will be best. And for bulk order, sea ship way is best but take much time.For urgent orders, we suggest via air to airport plus our ship partner send to your door.
Q6: Could you offer OEM tube light?
A6: Yes, we offer OEM tube light, the OEM tube light could offer your laber and your color box.
