laser chiller CW5200 for laser cutter
Specifications
Water cooling CW5200 for laser machine
High output voltage
Current,easy control of laser chiller
CE FDA ISO
Water cooling CW5200 for laser tube
Model |
CW-5000AG |
CW-5000BG |
CW-5000DG |
CW-5000AK |
CW-5000BK |
CW-5000DK |
Voltages |
AC220~240V |
AC208~230V |
AC100~110V |
AC220~240V |
AC208~230V |
AC100~110V |
Frequency |
50Hz |
60Hz |
50/60Hz |
50Hz |
60Hz |
50/60Hz |
Current |
1.4~2.1A |
3.5~5.6A |
1.4~2.1A |
3.5~5.6A |
||
Capacity |
6L |
|||||
Inlet and outlet hold |
Outside dimensions 10mm brass connector
|
Inside dimensions 8mm speedy connector |
||||
Max pumping lift |
10M |
100M |
||||
N.W |
26Kg |
29Kg |
||||
G.W |
31Kg |
34Kg |
||||
Dimensions(L*H*W) |
55*28*43cm |
|||||
Paching dimensions(L*H*W) |
71*41*62 cm
|
|||||
Water cooling CW5200 for laser tube
Features:
• It is suitable for cooling the laser tube under 150W, and the temperature can be adjusted precisely.
• You can choose different models according to local voltage and frequency.
• It can extend the using life of laser tube and ensure the engraving effect better.
• Small thermolysis water cooler, energy saving, long working life and simple operation
• With completed water flow and over high temperature alarm functions
• It can control the water temperature, precision is ±0.1°C, which provide stable working conditions for laser devices.
• Cool Capacity is 50W / °C.
• This series of water chillers adopt intelligent controller, which need not adjust the control parameters under normal
circumstances, it will automatically adjust control parameters according to room temperature changes, to meet the cooling requirement.
• CW-5000 water chiller has unique low flow alarm protection function, which ensures the cooling water cycle working safely.
• Specific disconnection alarm securing protection.
• Enclosed water tanks, water used for a long time.
• Equipped with alarm output port, can quickly protect sensitive components.
• High cost performance, low failure rate.
Packaging Details: standard carton box
Delivery Detail: 1-2 days after receiving the payment
