125cc Cub Motorbikes KA110-9A

Name: 125cc Cub Motorbikes KA110-9A
Brand: KAMAX
SKU: 120735269

Negotiable MOQ: 32 Units (Price negotiable depending on order volume and customization)

Key Specifications

Type:

Other, cub

Fuel:

Gas / Diesel

Displacement:

Other, 125cc, 110cc

Chongqing Diyang Science & Technology Development Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

chongqing

Delivery Detail:

Delivery time depends on order quantity.

Type Other, cub

Fuel Gas / Diesel

Displacement Other, 125cc, 110cc

Engine Type Other, 4-Stroke, 4-Stroke

Max. Speed 40 - 60km/h

Certification CE

Condition New

Brand Name KAMAX

Place of Origin Chongqing, China

Model Number KA110-9A

Brake(F/R) Fr.Disc/Re.Drum

Specifications

1.125cc cub
2.muscle appearance with high speed
3.Perfect driving experience

VIN(Frame No.)	LRY
Engine	110CC			125CC
Engine No.	152FMH			156FMI
Type	107cc, 4-Stroke Single cylinder,Air Cooled			120cc, 4-Stroke Single cylinder,Air Cooled
BorexStroke	52.4mm x49.5mm			56.4mm x49.5mm
Compression	9.1:1			9.1:1
Output, Max(Kw/Rpm)	5.2/8000			7.8/9000
Torque, Max(N.M/Rpm)	7.2/5000			8.2/7500
Ignition	CDI			CDI
Starting System	Electric/Kick			Electric/Kick
Transmission	4-Speed, Auto Clutch			4-Speed, Auto Clutch
Drive Train	Chain			Chain
Chassis
Suspension/Front	Hydraulic Spring Shock
Suspension/Rear	Hydraulic Spring Shock
Brakes/Front	Drum
Brakes/Rear	Drum
Tires/Front	2.50-17
Tires/Rear	2.75-17
Dimensions
LxWxH	1885mmx670mm x1050mm
Wheelbase	1215mm
Seat Height	790mm
Min ground clearance	150mm
Net Weight	95kg
Max Load	150kg
Max Speed(km/h)	≥80
Climbing Ability	≥16°
Fuel Tank Capacity	3.5L
Fuel Type	Unleaded Gasoline With Octane No. 91 Or Higher
Fuel consumption	1.8L/100km
Battery	12V/5Ah
Others
Color	Black	Blue	Red

Light	Yes
Packing Dimension	1650x450x860mm
Packing	20'GP 34Units, 40'GP 72Units, 40'HQ 108Units
