HBD 1.0-8.5M GFRP Beacon
The beacon is made of fiberglass reinforced plastic(GFRP) with a isophthalic NPG gel coat exterior and unsaturated polyester resin as the main material of body.
The GFRP beacon is robust and stable with cylinder module frame enhanced. The beacon consists of sections according to the height of beacon. And the individual segments are connected by inner flanges with high-tensile stainless bolts.
SPECIFICATION
1) Height of the beacon body:8.5m
2)Main body diameter:1000mm
3)The bottom diameter: 1850mm
4)Top platform diameter:1500mm
5) Foundation bolt PCD:1700mm.
6)All kinds of small marine lanterns and radar beacons can be equipped.
7)Powered by shore power UPS, solar photovoltaic system or wind-photovoltaic complementary power generation system.
FEATURE
Ø Easy transport and erect at remote light stations.
Ø Corrosion resistant materials.
Ø Robust with wind load up to 50m/s.
Ø Ideal for solar powered installations.
Ø Easy and safe access to the top platform.
Ø Lightning protection equipment available.
Ø Safe stainless lock with vandal-proof locking system.
Ø Available in all IALA colors.
EQUIPMENT
GFRP body with cage-shaped steel skeleton enhanced.
Socket type inner flanges for waterproof.
Stainless manguard.
Integral top platform with six outfalls.
Stainless lantern support.
Stainless lightning rod with copper leading-wire.
Inner stainless ladder.
Stainless connecting bolt.
Inner foundation bolt.
LED lantern.
Stainless anti-theft lock with special keys and stainless tamper-proof hinge.
