Navigational Buoy1. Long lifespan at least 15 years
2. No pullution for the sea water
3. Strong resistance ability
Hydrology Buoy
The HNF1.5 is a meteorological/oceanographic Hydrologic Monitoring buoy.This buoy suitable for measuring ocean meteorological parameters in Harbors.lakes ,and coastal area where the water depth is within 30 meters.
with the max ,wind speed 36m/s,and max ,flow rate 4 knot.
The buoy is moulded from polyurethane elastomer with internal stailess steel skelton enhanced and the body filled with closed-cell flexible foam which provides the buoy with great lightness and excellent mooring capacity .The choice of material ensures no risk of corrosion as well as excellent resistance to impacts.
The solar panels and maintenance-free batteries are used to provide energy to Data Acquisition units and wireless data transmission modules,which automatically transmit the data to the monitoring center through the GPS or satelite..
HNF1.5 buoy is equipped with three or four wells making the submerged sensors accessible without having to lift the buoy out of the water This reduces the operation cost because work can be done without large boats and heavy lifting equipment .The wells can also be used for current sensors .In the wells the sensors are well protected during handling as well as theft and vandalism .
Specification
1. Diameter:1500mm
2.Freeboard:400mm
3.Focal plane:1100mm
4.Weight:350kg
Features
1> High visibility reducing the risk of being run into and damaged by boats.
2> Long term unattended operatin due to large solar charging and battery capacity
3>Multi-parameter and multi-application real time monitoring is feasible
4>extremely robust construction Suitable for measuring oceanographic parameters waves,currents,water quality and meteorology
5>excellent mooring capacity
6>low maintenance
7>excellent resistance to collision
8>painting according to IALA recommendations
9>Excellent sealability of the instrument capsule
10>modular structure of bolt connection easy to transport the entire buoy no magnetic
Packaging details: packing in exporting case, or as the customers' required
Delivery time: 15 days after receiving the payment
Qinhuangdao Yaoxing Aids to Navigation Technology Co., Ltd. is a technological company which professionally manufactures all kinds of aquatic products. They have runned more than 10 kinds of marine products at present. And that includes the series of buoys, beacon, floating pontoon, composite material floating platform, FRP working boat and inflatable boat, etc.
