SAE5160 spring steel flat bar

FOB Price

USD $300 - $1,200 / Ton

1 Ton(Min.Order)

Supply Ability 80000 Ton / Tons per Month
Port FOB Shanghai
Payment Terms:T/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Grade:	spring steel	Dimensions:	dima 5-300	Standard:	AISI, ASTM, BS, DIN, GB, JIS
Place of Origin:	China	Brand Name:	XC	Model Number:	SAE5160
Type:	Spring Steel Bar	Application:	railway locomotives,auto,and construction machinery.

Product Description

SAE5160 Spring Steel Flat Bar

1. Material: 65Mn, 60Si2Mn, 50CrVA, SUP-9 etc.

2. Type: Smooth Plain, Double grooved.

3. Specifications: A variety of sizes from 5*45 to 30*150mm. We can produce according to customers' requirements, can customize for you.

4.Features: high strength & toughness; good hardenability & plasticity; excellent decarburization
; strong resistance & good elasticity; perfect machinability

5. Usage: Automobile laminated leaf spring, agricultural machinery & implements(rotary coulter), tools and machines etc.

6. Packing: Standard seaworthy packing or as customer required

7. Application: High strength, high toughness, large sectionand and important modified parts

8.Chemical Composition

Chemical Composition
Steel Grade	Chemical Composition (%)
	C	Si	Mn	Cr	V	W	B	Ni	Cu	P	S
	C	Si	Mn	Cr	V	W	B	Not more than
65	0.62-0.70	0.17-0.37	0.50-0.80	≤ 0.25				0.25	0.25	0.035	0.035
70	0.62-0.75	0.17-0.37	0.50-0.80	≤ 0.25				0.25	0.25	0.035	0.035
85	0.82-0.90	0.17-0.37	0.50-0.80	≤ 0.25				0.25	0.25	0.035	0.035
65Mn	0.62-0.70	0.17-0.37	0.90-1.20	≤ 0.25				0.25	0.25	0.035	0.035
55SiMnVB	0.52-0.60	0.17-1.00	1.00-1.30	≤ 0.35	0.08-0.16		0.0005-0.0035	0.35	0.25	0.035	0.035
60Si2Mn	0.56-0.64	1.50-2.00	0.70-1.00	≤ 0.35				0.35	0.25	0.035	0.035
60Si2MnA	0.56-0.64	1.60-2.00	0.70-1.00	≤ 0.35				0.35	0.25	0.035	0.025
60Si2CrA	0.56-0.64	1.40-1.80	0.40-0.70	0.70-1.00				0.35	0.25	0.035	0.025
60Si2CrVA	0.56-0.64	1.40-1.80	0.40-0.70	0.90-1.20	0.10-0.20			0.35	0.25	0.035	0.025
55SiCrA	0.51-0.59	1.20-1.60	0.50-0.80	0.50-0.80				0.35	0.25	0.025	0.025
55CrMnA	0.52-0.60	0.17-0.37	0.65-0.95	0.65-0.95				0.35	0.25	0.025	0.025
60CrMnA	0.56-0.64	0.17-0.37	0.70-1.00	0.70-1.00				0.35	0.25	0.025	0.025
50CrMnA	0.46-0.54	0.17-0.37	0.50-0.80	0.80-1.10	0.10-0.20			0.35	0.25	0.025	0.025
60CrMnBA	0.56-0.64	0.17-0.37	0.70-1.00	0.70-1.00			0.0005-0.0040	0.35	0.25	0.025	0.025
30W4Cr2VA	0.26-0.34	0.17-0.37	≤ 0.40	2.00-2.50	0.50-0.80	4.00-4.50		0.35	0.25	0.025	0.025

We produce spring flat steel. Our Jinguo Brand spring steel bar is in excellent quality and competitive price. We can produce and supply almost all grades of spring steel bars: 65Mn, 55Si2Mn, 60Si2Mn, 60Si2MnA, 55CrMnA, 60CrMnA, 60CrMnBA, 50CrVA; 60Si7, 55Si7, 55Cr3, 50CrV4, 51CrV4; SUP6, SUP7, SUP9, SUP9A, SUP10A; SAE1066, SAE1070, SAE5155, SAE5160, SAE9255, SAE9260 according to ASTM A29, ASTM A322, BS EN 10089-2002, DIN 17221-1988, GB/T 1222-1984, JIS G4801-2005.
