Help CenterInconel 601 Plate
US$ 10 - 100
MOQ: 100 Kilograms
Key Specifications
Get Latest Price
Place of Origin:
Shaanxi, China
Type:
Nickel Plate
Application:
Steam turbine,Liquid-fuel rocket
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin or Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Shaanxi, China
Type
Nickel Plate
Application
Steam turbine,Liquid-fuel rocket
Grade
inconel 601
Ni (Min)
80%
Powder Or Not
Not Powder
Model Number
inconel 601
Brand Name
HXTN
Specifications
Good quality products.-Fast production time.
-Good price.
-Strict quality control.
-Third party inspection available.
Inconel 601 Chemaical composition:
Alloy |
% |
Ni |
Cr |
Fe |
C |
Mn |
Si |
Cu |
Al |
P |
S |
601 |
Min. |
58 |
21 |
1.0 |
|||||||
Max. |
63 |
25 |
balance |
0.1 |
1.5 |
0.5 |
1 |
1.7 |
0.02 |
0.015 |
Inconel 601 Physical properties
Density |
8.1g/cm³ |
Melting point |
1320-1370°C |
Inconel 601 Alloy m inimum mechanical properties in the room temperature
Alloy state |
Tensile strength Rm N/mm² |
Yield strength
R P0. 2N/mm²
|
Elongation
A 5 %
|
Brinell hardness
HB
|
Annealing treatment |
650 |
300 |
30 |
- |
Solution treatment |
600 |
240 |
30 |
≤220 |
Characteristic as below
1.Excellent inoxidability in the high temperature.
2.Good resistance to carbonizing.
3.Good inoxidabilitiy in sulfur atmosphere
4.Good mechanical property in both room temperature and high temperature.
1.Excellent inoxidability in the high temperature.
2.Good resistance to carbonizing.
3.Good inoxidabilitiy in sulfur atmosphere
4.Good mechanical property in both room temperature and high temperature.
5.Good resistance to stress corrosion cracking, 601 have high creep rupture strength since it limits the carbon content and grain size, so recommend to use for above 500°C environment.
Inconel 601 Metallurgical structure
601 is face-centered cubic lattice structure.
Inconel 601 Corrosion resistance
One of the mainly performance of 601 is inexorability in high temperature, even in very inclement conditions. If in the process of heating and cooling cycle, 601 can generate the dense layer of oxide film to get high spalling resistance. 601 have good carbonation resistance. With excellent inoxidability in the high temperature of sulfur atmosphere since it has high chromium and aluminum content.
Inconel 601 Application field
1.The tray,basket and tool clamp in the heat treatment factory.
1.The tray,basket and tool clamp in the heat treatment factory.
2.Steel shares at annealing and radiation control, high-speed gas burners, Industrial furnace silk screen.
3.Separate tank of ammonia reforming and catalytic support grid of nitric acid producing.
3.Separate tank of ammonia reforming and catalytic support grid of nitric acid producing.
4.Exhaust system parts
5.Solid waste incinerator's combustion chamber
6.Channel support and soot dealing parts.
7.Detoxification exhaust system components
8.Oxygen re-heater
5.Solid waste incinerator's combustion chamber
6.Channel support and soot dealing parts.
7.Detoxification exhaust system components
8.Oxygen re-heater
Baoji Haixin advantages:
Good quality products.
-Fast production time.
-Good price.
-Strict quality control.
-Third party inspection available.
