Home > Consumer Electronics > Display & Accessories > LCD Module > LQ104S1DG2C SHARP COMPUTER MONITORS PC MONITORS 10.4" TFT LCD MONITOR LCD DISPLAY

LQ104S1DG2C SHARP COMPUTER MONITORS PC MONITORS 10.4" TFT LCD MONITOR LCD DISPLAY

LQ104S1DG2C SHARP COMPUTER MONITORS PC MONITORS 10.4" TFT LCD MONITOR LCD DISPLAY photo-1
LQ104S1DG2C SHARP COMPUTER MONITORS PC MONITORS 10.4" TFT LCD MONITOR LCD DISPLAY photo-2
LQ104S1DG2C SHARP COMPUTER MONITORS PC MONITORS 10.4" TFT LCD MONITOR LCD DISPLAY photo-3
LQ104S1DG2C SHARP COMPUTER MONITORS PC MONITORS 10.4" TFT LCD MONITOR LCD DISPLAY photo-4
LQ104S1DG2C SHARP COMPUTER MONITORS PC MONITORS 10.4" TFT LCD MONITOR LCD DISPLAY photo-5
LQ104S1DG2C SHARP COMPUTER MONITORS PC MONITORS 10.4" TFT LCD MONITOR LCD DISPLAY photo-6
US$ 1 - 999 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Japan
Brand Name:
SHARP
Model Number:
LQ104S1DG2C
Payment & Shipping
Payment Methods:
Port of Shipment:
keelung
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Japan
Brand Name SHARP
Model Number LQ104S1DG2C
Type TFT





LQ104S1DG2C


  • 10_4inch
  •
  • 10 - 15 inch / 25 - 40 cm
Active Area (W x H):
211.2 × 158.4 mm
Backlight System:
LED (built-in driver)
Brightness:
350 nits
Contrast Ratio:
500:1
Description:

True Industrial 4:3 aspect SVGA Module with 50,000-hr rated backlight, and built-in backlight driver. Module features extended temperature range plus anti-glare and 3H hard coating.

For Specifications, see your local Sharp Representative.

Diagonal Size:
10.4 inch (26.0 cm)
Display Mode:
Normally White
Family:
LQ104S1DG2C
Interface:
6-bit Digital: 262,144 colors
Operating Temperature Range:
-30 to +80°C
Outline Dimensions (W x H x D):
246.5 × 179.3 × 11.0 mm
Pixel Format:
800 x 600
Response Time:
35 ms
RoHS:
Yes
Status:
New
Storage Temperature Range:
-30 to +80°C
Type:
SVGA
Viewing Angle - 12 o clock:
50°
Viewing Angle - 6 o clock:
60°
Viewing Angle - side to side:
140°
