LQ104V1DG51 Sharp Lcd Display Panel 10.4" 640x480 Lcd Display Screen

LQ104V1DG51 Sharp Lcd Display Panel 10.4" 640x480 Lcd Display Screen thumbnail-1
LQ104V1DG51 Sharp Lcd Display Panel 10.4" 640x480 Lcd Display Screen thumbnail-2
LQ104V1DG51 Sharp Lcd Display Panel 10.4" 640x480 Lcd Display Screen thumbnail-3
LQ104V1DG51 Sharp Lcd Display Panel 10.4" 640x480 Lcd Display Screen thumbnail-4
LQ104V1DG51 Sharp Lcd Display Panel 10.4" 640x480 Lcd Display Screen thumbnail-5
LQ104V1DG51 Sharp Lcd Display Panel 10.4" 640x480 Lcd Display Screen thumbnail-6
LQ104V1DG51 Sharp Lcd Display Panel 10.4" 640x480 Lcd Display Screen photo-1
LQ104V1DG51 Sharp Lcd Display Panel 10.4" 640x480 Lcd Display Screen photo-2
LQ104V1DG51 Sharp Lcd Display Panel 10.4" 640x480 Lcd Display Screen photo-3
LQ104V1DG51 Sharp Lcd Display Panel 10.4" 640x480 Lcd Display Screen photo-4
LQ104V1DG51 Sharp Lcd Display Panel 10.4" 640x480 Lcd Display Screen photo-5
LQ104V1DG51 Sharp Lcd Display Panel 10.4" 640x480 Lcd Display Screen photo-6
US$ 1 - 999 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Japan
Brand Name:
SHARP
Model Number:
LQ104V1DG51
Contact Supplier Request Quote Chat Now
Longtek International Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
keelung
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Japan
Brand Name SHARP
Model Number LQ104V1DG51
Type TFT

LQ104V1DG51


Active Area (W x H):
211.2 x 158.4 mm
Backlight System:
2 x CCFT
Brightness:
350 nits
Contrast Ratio:
300:1
Description:
LCD Displays
Diagonal Size:
10.4 inch (26.0 cm)
Display Mode:
Normally White
Family:
LQ104V1DG51
Interface:
18-bit digital (6 bits/color)
Operating Temperature Range:
-10°C to +65°C
Outline Dimensions (W x H x D):
246.5 x 179.4 x 15.5 mm
Pixel Format:
640 x 480
Response Time:
60 ms
RoHS:
Yes
Status:
Discontinued
Storage Temperature Range:
-30°C to +70°C
Suggested Alternative Part Number:
LQ104V1DG5A
Type:
VGA
Viewing Angle - 12 o clock:
40 °
Viewing Angle - 6 o clock:
70 °
Viewing Angle - side to side:
140 °
