Automatic microwave popcorn pouch filling and sealing packing machine
Function and Characteristics
Model of GD6-200D Popcorn Rotary packing machine
1.Easy to operate,adopt advanced PLC from Germany Siemens, mate with touch screen and electric control system, the man-machine interface is friendly.
2.
Frequency conversion adjusts the speed: this machine uses frequency conversion equipment, can be adjusted within the range according to the needs of reality in production.
3, Automatic checking: no pouch or pouch open error, no fill, no seal. the bag can be used again, avoid wasting packing materials and raw materials.
4. Safty device: Machine stop at abnormal air pressure, heater disconnection alarm.
5,The width of the bags could be adjusted by electrical motor. Press the control-button could adjust the width of clips, easily operate, and save time.
6,It matchs with the glass safty door. The machine will stop working when you open the door. So that it could protect the safty of operators. At the same time, it could prevent dust.
7,
Use the plastic bearing, don’t need put on oil, less pollution.
8,
Use no oil vacuum pump, avoid polluting the environment in the production.
9, The packing materials loss low, what this machine is used the preformed bag, the bag pattern is perfect and has a high quality of the sealing part, this improved the product specification
10, Product or packing bag contact parts adopt stainless steel or other materials which accord with the food hygienic requirements, guarantee hygiene and security of the food
11, With different feeders changed to pack solid, liquid, thick liquid ,powder and so on.
Model of KJL-10 Mulithed Weigher
1..it can apply in : Dry & Processed Foods, Fresh Foods. Fox example: Sank Foods, Seeds(Pulses),Coffee(granules/beans), Tea, Sugar, Grated Cheese, Bakery Products, Candies & Confectionery, Rice, Nuts & Dried Fruits, Spices, small Pasta pieces, Pet Food(pellets) etc.
2,
Use the digital sensors to enhance speed, precision and anti-jamming capatiblity;
3,
.Optional language of operation. English ,Japanese,Chines,Italian ,German,Spanish,Russian etc.
4,IFrame with IP65 protection;
5,
Statistical Data-Inspect on screen and via optional printer output;
6.
.Options:Dimpled plate on all product contact surfaces, Overweight discharge equipment, Collection hopper,Printer
YJL-500B Liquid & Paste Filler
1,
it can apply in: measure liquid and catsup like syrup, redeye,peanut butter,scour and so on.
2,This machine is semiautomatic piston style liquid canning machine.
4,The design of the machine is in reason with artful model , and it is convenient to handle.
5.The part where touch to the material is made of stainless steel is accord with the request of GMP.
6,The acnning mete and career can be acconnodated, it is accurate.
7,The canning cobbra of the machine use the setting of defending leak and drawbench.
8,Double hopper,thermal insulation, With fluid control devices
Model of TSZ-100 Bucket elevator Feeder
This kind of elevator is used mainly to convey the solid food ,such as rice, chip potato ,candy ,etc.it composes the automatic quantitative packing system combined with the weigher and packing machine, which is applying widely. Be made of 304 stainless steel and plastic (PP) which is hygienicand healthy .the elevator is controlled automatically.
Sale Frame: carbon steel & powder coating
Specifications
Working position |
six-working position |
Pouch material |
Laminated film |
Pouch pattern |
Special microwave popcorn pouch |
Pouch size |
W:100-210mm L:100-350mm |
Filling Scope |
10-1000g |
|
Weight accuracy
|
±0.5-1.5g |
Speed |
≤45pouches/min(The speed depends on the product status and flling weight)) |
Voltage |
380V 3phase 50HZ/60HZ |
Total power |
5.5KW |
Compress air |
0.6m3/min(supply by user) |
Working process
1)Giving pouch
2)1 Open pouch 1st
3)2,Open pouch 2nd &under-side folding bag
4))Filling(corn & butter)
5)sealing 1st , & upside folding bag
6)sealing 2nd & output packages.
