miniature ball bearing 626 /ball bearing /626z/626zz

Specifications

626 ball bearing
1:Low vibration
2 low noise
3 high precision and durability

WELCOME TO QJ BEARING MANUFACTURE



626 ball bearing

1:Low vibration
 2 low noise
 3 high precision and durability



if you need bearing ,any kinds any price ,pls contact us :

SKYPE:xiangyuchina

QQ:270697965

Phone"86-133612372302

Bearing Type



1, single row deep groove ball bearings
2, single row deep groove ball bearings with dust cover
3, with dust cover, seal ring of single row deep groove ball bearings
4, the outer ring on the stopper groove and snap ring of single row deep groove ball bearings
5, deep groove ball bearings with filling slots
6, double row deep groove ball bearings



In accordance with the size of the deep groove ball bearings can be divided into:
(1) miniature bearings ---- nominal diameter size range of less than 26mm of bearing;
(2) small bearing ---- nominal diameter size range of 28-55mm bearings;
(3) small and medium-sized bearings ---- nominal diameter size range of 60-115mm bearing;
(4) in the large bearing ---- nominal diameter size range of 120-190mm bearings
(5) large bearing ---- nominal diameter size range of 200-430mm bearing;
(6) large bearings ---- nominal diameter size range of 440mm above the bearing.



TYPE	INEER.BORE(mm)	OUTER BORE(mm)	WIDTH(mm)	TYPE	INEER.BORE(mm)	OUTER BORE(mm)	WIDTH(mm)
682ZZ	2	5	2.3	606ZZ	6	17	6
692ZZ	2	6	3	626ZZ	3	19	6
602ZZ	2	7	3.5	636ZZ	6	22	7
683ZZ	3	7	3	687ZZ	7	14	5
693ZZ	3	8	4	697ZZ	7	17	5
603ZZ	3	9	5	607ZZ	7	19	6
623ZZ	3	10	4	627ZZ	7	22	7
633ZZ	3	13	5	637ZZ	7	26	9
684ZZ	4	9	4	688ZZ	8	16	5
694ZZ	4	11	4	698ZZ	8	19	6
604ZZ	4	12	4	608ZZ	8	22	7
624ZZ	4	13	5	628ZZ	8	24	8
634ZZ	6	16	5	638ZZ	8	28	9
685ZZ	5	11	5	689ZZ	9	17	5
695ZZ	5	13	4	699ZZ	9	20	6
605ZZ	5	14	5	609ZZ	9	24	7
625ZZ	5	16	5	629ZZ	9	26	8
635ZZ	5	19	6	639ZZ	9	30	10
686ZZ	6	13	5	6000ZZ	10	26	8
696ZZ	6
