Model |
YJS-D7504 |
|
System |
GUI: |
Graphic User Interface(OSD Menu) |
Operation system: |
Linux(embedded) |
|
Multiplex Operation: |
Pentaplex : Preview, record, playback, backup, network |
|
Video/ Audio input |
password security : |
Multi-user management operation |
Analog video input: |
4CH,BNC, 1.0p-p, 75Ω, |
|
Audio input: |
1CH, RCA, 2.0Vp-p,600kΩ |
|
Video/Audio output |
HDMI Output: |
support |
VGA output: |
1CH, resolution: 800*600, 1024*768,1280*1024 |
|
Display: |
1ch / 4ch optional |
|
Video standard: |
PAL/NTSC |
|
CVBS Output: |
1CH,BNC, (1.0Vp-p,75Ω) Resolution: PAL (704*576), NTSC(704*480) |
|
Audio output: |
1CH, RCA, (Linear electrical level, 600Ω) |
|
Video/Audio encoding parameters |
Video compression: |
H.264 |
Display frame rate: |
PAL: 100fps (4 x 25 fps)NTSC: 120fps (4 x 30 fps) |
|
Record frame rate: |
PAL: 100 fps(4 x 25 fps) NTSC:120 fps(4 x 30 fps) |
|
video coding resolution: |
4CIF(704X576) |
|
video frame rate: |
1-25FPS |
|
video bit rate: |
changeable and fixed bit rate(optional) |
|
Stream type: |
composite/ video |
|
Audio compression: |
ADPCM |
|
Recording Mode: |
Support normal / timer / alarm / motion detection recording |
|
search video files : |
By time period / channel / video type |
|
Audio bit rate: |
8-32kbps |
|
Dual steaming: |
support |
|
Mobile phone monitoring: |
Android / iphone / blackberry / windows / symbian |
|
Recording resolution: |
Recording: 4ch D1 Playback: 4ch D1 |
|
Synchronous Playback: |
4ch |
|
Hard Disk Driver |
Type: |
2 SATA interface |
capacity: |
Maximum 3TB HDD |
|
recording type(Audio) : |
audio and video recording simultaneously |
|
remote control /mouse |
support |
|
Network: |
Support IE/PPP0E/DDNS, DHCP,DDNS,PPPoE, IE view, and CMS central control |
|
NAT |
Support |
|
Network interface: |
1 RJ45 10M/100M, adaptive Ethernet interfaces |
|
Serial interface: |
1 standard RS-485 serial interface |
|
interface: |
2, USB 2.0 |
|
software upgrade: |
Support USB/ network upgrade |
|
With CE FCC RoHS certificates.
