china manufacturer 802.3at 25.w 5v 12v 24v poe splitter 100m
Product Model |
Product Description |
YJS-POE2501A |
15.4W PD POE splitter |
1) Support the IEEE 802.3af the Power over Ethernet standard. | |
2) Support 10/100Mbps data transmission. | |
3) PD receiving end supports a variety of voltage of 12V-48V transfer, user-friendly UPS DC power supply. | |
4) Provide 12V voltage to adapt to a variety of network equipment. | |
5) Circuit isolation protection, effective protection of electrical equipment. | |
6) High quality design, guarantees the stability and reliability of the equipment in work. | |
Technical Specification:
POE Parameters |
1) Maximum Power: 15.4W (IEEE 802.3af) 2) Input voltage :44-57V Output voltage: 12V 3) Power pin: Support both 1/2+,3/6- and 4/5+,7/8- |
Connect Port |
1) Input: an input RJ45 interface 2) Output: an output RJ45 connector and a DC output interface 3) Data transfer rate: 10/100Mbps 4) The maximum transmission distance: 100 meters |
Network standards |
IEEE802.3i 10 BASE-T, IEEE802.3i 100 BASE-TX, IEEE802.3x flow control IEEE802.3af /IEEE802.3at |
LED indicator |
PoE, DC output |
Output |
12V |
Certificate |
CE,FCC,ROHS |
Working Term. |
-15°C-60°C |
Storage Term. |
-40°C-70°C |
Operating Humidity |
20%-85%,Non-condensing |
size |
94*70*26 mm (L*W*H) |
Weight |
70g/pcs |
Warranty |
One year |
