Performance characteristics:
•The structure of this machine is welding bracket and overall welding.
•The machine is equipped with a water tank and water cooling system.
•Three axes adopt Taiwan HIWIN high precision linear rail.X and Y axes adopt rack and pinion transmission,Z axis adopt ball screw with high precision and long life time.
Applicable industry:
•This machine is widely used in stone industry, such as natural marble, granite, artificial stone, tombstones, milepost, ceramic tile, glass and other materials.
Technical parameters:
Model |
HG-1325S |
Structure of the machine |
Overall welding T-solt |
Working area |
1300X2500X300mm |
Transmission mode |
XY Axis adopt high precision gear rack,Z axis with imported Ball screw |
Drive&motor |
YAKO 2811 Stepper motor |
Guide |
Hiwin Linear Rails |
Max. Working Speed |
20mm/min |
Mechanical accuracy |
0.01mm |
Power Supply |
AC110/220/380 50Hz |
Spindle power |
4.5kw water-cooling |
Spindle speed |
0 - 24000rpm |
Control system |
A18 Rich Auto DSP handle controller system |
Application software |
Wen Tai, Artcam, Type3 |
Carving instruction |
Standard G code |
Working table |
Hard PVC+Water tank+Roller Ball |
Sample:
