Help CenterHG-1212 Model 1.5 kw Spindle Cnc Router Machine 1212
Related Products
-
HG-1212 Factory Directly on Sale Cnc Rubber Engraving MachineUS$ 2,500 - 3,000MOQ: 1 Set -
HG-1224 Hot Sale Model Hobby Cnc Router MdfUS$ 3,000 - 4,000MOQ: 1 Set
-
HG-1224 Factory Directly on Sale Cnc Router for HdpeUS$ 3,000 - 4,000MOQ: 1 Set
-
HG-1212 Factory Directly on Sale 2014 Newest Design Hobby Cnc Router for SaleUS$ 2,500 - 3,000MOQ: 1 Set
-
HG-1224 Factory Directly on Sale Hot Sale Plastic Cnc Cutting MachineUS$ 3,000 - 4,000MOQ: 1 Set
Specifications
HG-1212 model 1.5 kw spindle cnc router machine 12121. Cast iron
2. Ball screw
3. 1.5 kw spindle
4. CE ISO
HG-1212 model 1.5 kw spindle cnc router machine 1212
cnc router machine 1212 Features
1. Import high precision preloaded backlash ball screw, the movement is generated when clearance to reduce to the smallest
2. Use the high quality brand drive, faster than the original model improves the nearly 2 meters
3. Import guide rail, self lubricating block, make each direction force equal to ensure that the mechanical precision and strength.
4. Adopts the breakpoint memory way, to guarantee available in accident (broken knife) or the next day processing
5. Unique multiple work piece processing origin preservation mode
6. Gantry mobile, strengthen mesa, durable, long time use deformation, better positioning accuracy Plate production not only make carving fine without jagged, basal level off is smooth and contour is clear, and cutting 2 cm organic glass also relaxed freely.
7. Machine body is welded steel tube or whole cast iron,it's up to you.
cnc router machine 1212 Applicable Materials
Wood, acrylic, PVC, density boards, artificial stones, organic glass, plastics and soft metal sheets such as copper and aluminum
cnc router machine 1212 Specification
Model |
HG-1212 |
XYZ Working Size |
1200*1200*110 mm |
Machine body |
whole cast iron |
Table surface |
T-slot table |
XY structure |
Ball screw drive, round rail |
Z structure |
Ball screw drive, round rail |
Spindle |
1.5 kw water cooled |
Spindle speed |
24000 RPM |
Drive motor |
Stepper system |
Max. Rapid Travel Rate |
15000 mm/min |
Max. Working speed |
10000 mm/min |
Control system |
NCstudio |
Software |
Type3, Artcam, Ucancam |
Command |
G code |
Machine precision |
0.01 mm |
Repositioning precision |
0.03 mm |
Working voltage |
AC 220/380V |
Machine Size |
1600mmX1600mmX1500mm |
Net weight |
700KG |
Dust collector |
optional |
Remark |
We can customize the model for any processing size |
Parts of the machine can do some changes as your requirement:
1. Motor (stepper or sever motor)
2. Spindle ( air-cooling or water-cooling spindle)
3. Guide rail (round guide rail or square guide rail)
4. The table of the machine (Vacuum table, T-slot table, Combination of Vacuum table & T-slot table, normal table, table moving)
cnc router machine 1212 Standard accessories
PCI card, Communication cable, Water cooling system, Power cable, Clamp, Wrench, Bit, Collet, Other tools
cnc router machine 1212 Warranty
24 months for machine. Also we supply lifetime service online 24 hours a day MSN, Skype, Yahoo, Gmail and so on. You can also contact us by email, and we will reply in 24 hours, or by phone if urgently.
cnc router machine 1212 Samples
We usually use below parts for our machine
Main Products
cnc router machine 1212 Production Procedure
cnc router machine 1212 Certification
Company Advantages
1, First-class factory meets international production plant's standard, ten years' manufacture and export experiences
2, Own most advanced domestic cnc machining production equipments
3, 5-9 days machine production time, one year warranty and lifetime free maintenance
4, OEM and ODM services available
5, Same quality, our price and service are better; Same price, our quality and service are better
6, with CE, FDA, SGS, ISO9000 certifications
