QR6639N -- white horse ceramic floor wall tile

FOB Price

USD $6.25 - $7.15 / Square Meter

499 Square Meters(Min.Order)

Supply Ability 8000 Square Meter / Square Meters per Month
Port FOSHAN SHENZHEN NANSHA
Payment Terms:T/T L/C D/P D/A Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:	Guangdong, China	Brand Name:	JDD	Model Number:	QR6639N
Size:	300 x 600mm, 600 x 600mm	Material:	Porcelain Tiles	Usage:	Interior Tiles
Function:	Acid-Resistant, Antibacterial, Firebrick, Heat Insulation, Non-Slip, Wear-Resistant	Surface Treatment:	Glazed Tiles	Color Family:	Grays
Tile Type:	Floor Tiles, Wall Tiles

Product Description

QR6639N --white horse ceramic floor wall tile

Product Description

JDD QUARTZ SERIES: QR6639N,grey color,matt finish

SIZE	PCS/BOX	SQM /BOX	KGS/BOX	BOXES/PALLET	BOXES / CONT	SQM / CONT	KGS /CONT
600x600 MM	4	1.44	30.5	30	870	1252.8	26535
300x600 MM	8	1.44	32.5	32	800	1152	26000

TEST REPORT:

EN 14411:2012 Ceramic tiles-Definitions,classification,characteristics,evaluation of conformity and marking Annex G Requirements for dry-pressed ceramic tiles with low water absorption of Group B Iα (Eb≤0.5%)
Clause	Properties	Test Method	Requirements	Results	Verdicts
A	Dimensions and surface quality
A.1	Length and Width The permissible deviation of the average size for each tile(4 side) from the work size	EN ISO 10545-2	±0.6%	-0.02%~0	P
A.1		EN ISO 10545-2	±2.0MM	-0.1MM~0	P
A.2	Thickness
	The thickness shall be specified	-	Declared thickness	9.5mm	-
	The permissible deviation,of the average thickness of each tile from the work size thickness	EN ISO 10545-2	±5%	+3.61%~+4.61%	P
		EN ISO 10545-2	±0.5MM	+0.3MM~+0.4MM	P
B	Physical properties
B.1	Water absorption Percent mass fraction	EN ISO 10545-3	Eb≤0.5%	0.18%	P
B.1	Water absorption Percent mass fraction	EN ISO 10545-3	Individual maximum 0.6%	0.16%~0.22%	P
B.2	Breaking strength,in N	EN ISO 10545-4	≥1300	2213	P
B.3	Modulus of repture,in N/mm2 Not applicable to tiles with breaking strength≥3000N	EN ISO 10545-4	Minimum 35	43.3	P
B.3		EN ISO 10545-4	Individual minimum 32	39.6~47.0	P
B.4	Abrasion resistance Resistance to surface abrasion of glazed tiles intended for use on floors	EN ISO 10545-4	Report abrasion class	Class 3	-
B.4		EN ISO 10545-4	Report cycles passed	1500	-
B.6	Thermal shock resistance	EN ISO 10545-9	Pass	Fully resistance	P
B.7	Crazing resistance:glazed tiles	EN ISO 10545-11	Pass	Fully resistance	P
B.9	Slipperiness	DIN 51130	Declared value	α ges:10.3°	-
B.9	Slipperiness	DIN 51130	Declared value	Classification:R10	-
B.14	Reaction to fire	CWT	Class A1 or A1 fl	Class A1 fl	P
C	Chemical properties
C.1	Resistance to staining
	a)Green staining agent in light oil	EN ISO 10545-14	Minimum Class3	Class 5	P
	b)Red stainning agent in light oil	EN ISO 10545-14	Minimum Class3	Class 5	P
	c)Iodine,13g/L solution in alcohol	EN ISO 10545-14	Minimum Class3	Class 5	P
	d)Olive oil	EN ISO 10545-14	Minimum Class3	Class 5	P
C.2	Resistance to chemicals
	Resistance to household chemicals and seimming pool salts
	a)Hosehold chemicals:Ammonium chloride,100g/L	EN ISO 10545-13	Minimum class B	GA(V)	P
	b)Swimming pool salts:Sodium hypochlorite solution,20mg/L	EN ISO 10545-13	Minimum class B	GA(V)	P
	Resistance to low concentrations of acids and alkalis
	a)Hydrochloric acid solution,3%(v/v)	EN ISO 10545-13	Declared value	GLA(V)	-
	b)Citric acid solution,100g/L	EN ISO 10545-13	Declared value	GLA(V)	-
	c)Potassium hydroxide,30g/L	EN ISO 10545-13	Declared value	GLA(V)	-
	Resistance to high concentrations of acids and alkalis
	a)Hydrochloric acid solution,18%(v/v)	EN ISO 10545-13	Declared value	GHA(V)	-
	b)Lactic acid,5%(v/v)	EN ISO 10545-13	Declared value	GHA(V)	-
	c)Potassium hydroxide,100g/L	EN ISO 10545-13	Declared value	GHA(V)	-
Possible test case verdicts 1.P(ass) :Test item does meet the requirement 2.F(all) :Test item does not meet the requirement 3.- :Verdict was not carried out 4.N/A :Test case does not apply to the test item

Packaging & Shipping

Our Services

1. JDD INDUSTRY CO,. LTD has exported all kinds of tiles for more than 15 years. we know all trade rules of different countries .

2. We have experienced staff and professional QC team to ensure good quality and smooth delivery for clients.

3. Wild selections for all kinds of tiles, superior quality and competitive price

4. We support clients good sea freight for CNF terms from our shipping company.

5 OEM / ODM for all kinds of floor and wall tiles.

6.Except T/T, all other payment terms are negotiable.

Contact Us

Foshan JDD Ceramic Co., Ltd.: Contact nameStephy Deng; Phone0086-757-66836556; AddressJDD BUILDING NO.9,TAOBO NO.1 ROAD ,NANZHUANG HUAXIA CERAMIC CITY Foshan,Guangdong
