Supermarket Display Shelving/ Perforated Back Panel Shelves

Supermarket Display Shelving/ Perforated Back Panel Shelves thumbnail-1
Supermarket Display Shelving/ Perforated Back Panel Shelves photo-1
US$ 30 - 150 MOQ: 20 Sets
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
MAIJIAYI
Model Number:
MJY-SH010
Contact Supplier Request Quote Chat Now
Suzhou Maijiayi Commercial Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangsu, China
Brand Name MAIJIAYI
Model Number MJY-SH010
Material Other, Metallic, high steel
Feature Single-sided
Type Other, Supermarket Rack, Perforated back panel
Style Light Duty
Capacity 30-60KG/layer
Layer 4 layer

Specifications

1. Used for store&shop, supermarket and hypermarket
2. Single-side: L1200*D450*H1800MM
3. Material: metallic
4. CE&ISO9001



Product Description

Perforated Back Panel Supermarket Shelf, Punched Supermarket Shelving, Supermarket Gondola Shelving



Specification:



Specification

Double-sided: 1200*900*1800mm

Single-sided: 1200*500*1800mm

End shelf: 900*450*1800mm

Size of upright/post

30*60*(1.5-2.0)mm/40*60*1.8(2.0)mm/40*80*(1.8-2.5)mm



Thickness of bracket

1.5-2.5mm.  L:300-500mm.

Thickness of shelf

0.5-1.0mm. L: 890/960/1160*300/350/400/450/500/550mm

Thickness of perforated backboard

0.7-1.0mm. L: 885/950/1150*147/297/347mm

Capacity

30-180KG/layer

Layer(s)

3/4/5layers





I Features:

1) Color and size can be adjusted according to your requirements;

2) Surface treatment: Epoxy powder coated, dry quickly providing a tough, protective coating with excellent hardness, anti-corrosion , low volatility and water clean up, more heat resistant, and color optional;

3) Easy to install and dismantle;

4) Available with light, medium, and heavy carrying capacities;
5) High quality and good appearance;

6) The most commonly used in all supermarket systems;

7) each layer carrying up to 30-150kg;

8) The reliable and efficient service before and after deal.



Supermarket Display Shelving/ Perforated Back Panel Shelves



  II More details

Model

Perforated Supermarket  shelf

Post or upright size

40*80

30*60

Side(oneside or inside

One side

Double side

One side

Double side

Specification

1200*550*2000

1200*1100*2000

1200*450*1800

1200*900*1800

Thickness of board

0.6mm

0.6mm

0.5mm

0.5mm

Thickness of post or upright

1.8mm

1.8mm

1.35mm

1.35mm

Thickness of back panel

0.7mm

0.7mm

0.7 mm

0.7mm

Capacity(each layer)

120-150kg

150-200kg

100-120kg

120-150kg

Quantity of layers

5

5 each side

5

5 each side

Cubic meter

0.088

0.163

0.068

0.129

color

White or others

White or others

White or others

white or others



Model

Perforated Supermarket shelf

Post or upright size

40*60

30*70

Side(oneside or inside

One side

Double side

One side

Double side

Specification

1200*550*2000

1200*1100*2000

1200*450*1800

1200*900*1800

Thickness of board

0.6mm

0.6mm

0.5mm

0.5mm

Thickness of post or upright

1.8mm

1.8mm

1.35mm

1.35mm

Thickness of back panel

0.5mm

0.5mm

0.5 mm

0.5mm

Capacity(each layer)

100-150kg

100-200kg

100-120kg

120-150kg

Quantity of layers

5

5 each side

5

5 each side

Cubic meter

0.088

0.163

0.068

0.129

color

White or others

White or others

White or others

White or others





Supermarket Display Shelving/ Perforated Back Panel Shelves





Products Deatails:



Supermarket Display Shelving/ Perforated Back Panel Shelves

Supermarket Display Shelving/ Perforated Back Panel Shelves  Supermarket Display Shelving/ Perforated Back Panel Shelves







Supermarket Display Shelving/ Perforated Back Panel Shelves





Supermarket Display Shelving/ Perforated Back Panel Shelves





 Supermarket Display Shelving/ Perforated Back Panel Shelves

Packaging & Shipping



Package:

1,  shelf and backpanel : carton ,

2,upright :by bubble foam,

3, bracket : by woven bag  ;

4 plastic label and rail guard; carton.

Shipping: the best chocie by sea.



item

packing

Qty/pk

Packing size

upright

Bubble foam

6pcs



Base

carton

10pcs



Layer shelf

carton

10pcs



Back panel

carton

20pcs



Plastic label

carton

200pcs



Kick panel

carton

40pcs



Front guard

carton

200pcs





 Supermarket Display Shelving/ Perforated Back Panel ShelvesSupermarket Display Shelving/ Perforated Back Panel Shelves



Supermarket Display Shelving/ Perforated Back Panel Shelves  Supermarket Display Shelving/ Perforated Back Panel Shelves





Company Information

Supermarket Display Shelving/ Perforated Back Panel Shelves





 Supermarket Display Shelving/ Perforated Back Panel Shelves

 Supermarket Display Shelving/ Perforated Back Panel Shelves





FAQ



Pls kindly inform us the below information for us make a quotation:

1. AUTO CAD drawings

2. Width, height, length of the shelf

3. type  of shelf /upright

4. How many layers you need?

5. Loading capacity of each layer

6. LAR Color you want
