Help Center125A AC Contactor MC1-D80 AC Coil
US$ 4 - 60
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
SMUN
Model Number:
MC1-D80
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGO
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
AC Contactor 50A 24V48V/110V/220VDC Coil MC1-E3211 Coil DCUS$ 2 - 60MOQ: 1 Piece -
MC1-D8011 AC Contactor 80A 24v48v110v220v dc CoilUS$ 2 - 60MOQ: 1 Piece
-
60A AC Contactor 24v 36v 110v 220v380v MC1-D40US$ 4 - 60MOQ: 1 Piece
-
63A AC Contactor MCJ19-D63US$ 2 - 50MOQ: 1 Piece
-
AC Contactor 380V 9A 12A 18AUS$ 2 - 60MOQ: 1 Piece
Place of Origin
Zhejiang, China
Brand Name
SMUN
Model Number
MC1-D80
Electricity Type
AC
Number of Pole
4
Phase
3
Main Circuit Rating Voltage
690v
Main Circuit Rating Current
150a
Specifications
MC1-D80 Magnetic contactorAC3 380V 3P+N/O+N/C
9A-95A
MC1-D80 Magnetic contactor
AC3 380V 3P+N/O+N/C
9A-95A
| Type | MC1-D09 | MC1-D12 | MC1-D18 | MC1-D25 | MC1-D32 | ||
| Rated operational current(A) | 380V | AC-3 | 9 | 12 | 18 | 25 | 32 |
| AC-4 | 3.5 | 5 | 7.7 | 8.5 | 12 | ||
| 660V | AC-3 | 6.6 | 8.9 | 12 | 18 | 21 | |
| AC-4 | 1.5 | 2 | 3.8 | 4.4 | 7.5 | ||
| Rated conventional thermal current(A) | 20 | 20 | 32 | 40 | 50 | ||
| rated insulation voltage (V) | 690 | 690 | 690 | 690 | 690 | ||
| Rated operational power in category AC-3KW | 220V | 2.2 | 3 | 4 | 5.5 | 7.5 | |
| 380V | 4 | 5.5 | 7.5 | 11 | 15 | ||
| 660V | 5.5 | 7.5 | 10 | 15 | 18.5 | ||
| Operation cycles (timers/hour) | Electrical | AC-3 | 1200 | 1200 | 1200 | 1200 | 1200 |
| AC-4 | 300 | 300 | 300 | 300 | 300 | ||
| Mechanical | 3600 | 3600 | 3600 | 3600 | 3600 | ||
| Electrical life (*10*5times) | AC-3 | 100 | 100 | 100 | 100 | 100 | |
| AC-4 | 20 | 20 | 20 | 20 | 20 | ||
| Mechanical life(*10*5times) | 1000 | 1000 | 1000 | 1000 | 1000 | ||
| matching fuse model | RT16-20 | RT16-20 | RT16-32 | RT16-40 | RT16-50 | ||
| Coil specification | |||||||||
| Coil code | B5 | VV5 | F5 | M5 | Q5 | B7 | F7 | M7 | Q7 |
| Coil voltage(V) | 24V | 36V | 110V | 220V | 380V | 24V | 110V | 220V | 380V |
| Coil Hz | 50Hz | 50Hz | 50Hz | 50Hz | 50Hz | 50/60Hz | 50/60Hz | 50/60Hz | 50/60Hz |
