Home > Electrical & Electronics > Power Supply & Distribution > Switching Power Supply > CE RoHS Approved 2 Years Warranty 10w Msf Series 220v 15v 1a Led Ultrathin Power Supply
CE RoHS Approved 2 Years Warranty 10w Msf Series 220v 15v 1a Led Ultrathin Power Supply
US$ 3.2 - 5.8
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Weihao
Model Number:
MSF-10-15
Payment & Shipping
Payment Methods:
Port of Shipment:
ningbo shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Quality Led 15v 1.6amp Ultrathin Power Supply 20wUS$ 3.5 - 5.2MOQ: 1 Piece -
High Quality 15w NES 15v Single Output 1a dc Led Power SupplyUS$ 4 - 6.5MOQ: 1 Piece
-
CE RoHS Approved Factory Outlet 15volt 2.4amps Power Supply 35wUS$ 5.5 - 7.2MOQ: 1 Piece
-
Weho New Products Led 110v/220v ac Power 15v dc Converter Smps 50wUS$ 6 - 8.2MOQ: 1 Piece
-
Nes Model 15v Switching Power Supply 25w Cctv/led SmpsUS$ 4.8 - 6.2MOQ: 1 Piece
Place of Origin
Zhejiang, China
Brand Name
Weihao
Model Number
MSF-10-15
Output Power
1 - 50W
Output Type
Single
Input Voltage
220V
Output Voltage
15V
Output Frequency
47~63HZ
Output Current
0.8A
220v 24v
1.CE ROHS
2.2 year warranty
3.72% efficiency
4.high quality
WH CE RoHS approved 2 years warranty 10w msf series 220v 15v 1a led ultrathin power supply
| Model | MSF-10-5 | MSF-10-12 | MSF-10-15 | MSF-10-24 | |
| output | DC output voltage | 5V | 12V | 15V | 24V |
| DC Current range | 0~2A | 0~1A | 0~0.8A | 0~0.5A | |
| Wave&noise | 50mvp-p | 50mvp-p | 50mvp-p | 50mvp-p | |
| Inlet wire stability | ±0.5% | ±0.5% | ±0.5% | ±0.5% | |
| Load stability | ±1% | ±0.5% | ±0.5% | ±0.5% | |
| Adjustable range for DC voltage | ±10% | ±10% | ±10% | ±10% | |
| Input Voltage range | 85~264VAC,120~370VDC | ||||
| Impact current | Cold start current 30A/230VAC | ||||
| frequency | 47~63HZ | ||||
| efficiency | 68% | 71% | 72% | 75% | |
| Overload protection | 105%~135% cut off the output,automatic recovery | ||||
| Setup,rise,hold up time | 200ms ,50ms , 20ms/230VAC at full load | ||||
| environment | Working temperature | -10°C- +50°C | |||
| safety | Withstand voltage | I/P-O/P:1.5KVAC I/P-FG:1.5KVAC O/P-FG:0.5KV 1minute | |||
| Isolated resi stance | I/P-O/P,I/P-FG,O/P-FG:500VDC/100MΩ | ||||
| others | Dimension | 78*48*21mm(L*W*H) | |||
| weight | 0.15kg | ||||
| packing | 24.5*17.5*26.5CM/100PCS/15kg | ||||
Product Description
Packaging & Shipping
we use 4 trips to reinforce our carton,
the international standards package methods guaranteed our goods safety during transportation
we are a professional manufacturer of power supplies ,
all of our products have approved CE ROHS and ISO9001:2008
