PL9611 0-360v/300w DC Electronic Load
USD $580 - $600
/ Piece
1 Piece(Min.Order)
- 100 Piece / Pieces per Month
- SHENZHEN GUANGZHUO HK
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
Place of Origin: | Guangdong, China | Brand Name: | NAPUI | Model Number: | PL9611 |
Product Description
PL9611 0-360v/300w DC Electronic Load
Model | PL9610 | PL9611 | |
Input Voltage | 0~360V | ||
Rated Valued | Input Current | 1mA~30A | |
Input Power | 150W | 300W | |
Range | Accuracy | Resolution | |
Load Accuracy | 0-36V | ±(0.05%+0.03%FS) | 1mV |
0-360V | ±(0.05%+0.03%FS) | 10 mV | |
0-3A | ±(0.05%+0.05%FS) | 0.1 mA | |
0-30A | ±(0.05%+0.05%FS) | 1 mA | |
CV Model | 1.5V-36V | ±(0.05%+0.03%FS) | 1mV |
1.5V-360V | ±(0.05%+0.03%FS) | 10mV | |
CC Model | 0-3A | ±(0.05%+0.05%FS) | 0.1 mA |
0-30A | ±(0.05%+0.05%FS) | 1mA | |
CR Model | 0.05Ω-5Ω | ±(0.2%+0.2%FS) | 0.001Ω |
(When input voltage and current value≥10%FS) | 0.5Ω-50Ω | ±(0.1%+0.1%FS) | 0.01Ω |
5Ω-500Ω | ±(0.1%+0.1%FS) | 0.1Ω | |
500Ω-5KΩ | ±(1%+1%FS) | 1Ω | |
Fix power model | 0-50W | ±(0.1%+0.1%FS) | 1 mW |
(When input voltage and current value≥10%FS) | 0-150W | ±(0.1%+0.1%FS) | 10 mW |
0-300W | ±(0.1%+0.1%FS) | 0.1 W | |
0-9.9999V | ±(0.05%+0.03%FS) | 0.1mV | |
Voltage measurement accuracy | 10.000-99.999V | ±(0.05%+0.03%FS) | 1mV |
100.00-360.00V | ±(0.05%+0.03%FS) | 10mV | |
Current measurement accuracy | 0-9.9999A | ±(0.05%+0.05%FS) | 0.1 mA |
10.000-30.000 | ±(0.05%+0.05%FS) | 1mA | |
Test the battery function | Input Voltage= 0.8-360V Max. Capacity= 999A/H | ||
Resolution ratio=0.1mA Discharge time=1~60000sec | |||
Dynamic Testing Model | T1&T2(A Value or B value test time):0.1mS-999S Error<2.5% + 0.1mS | ||
Protective Range | >Rated condition 5% | ||
Input terminal Impedance | ≥200KΩ | ||
Dimension | W*H*D 230mm*100mm*350mm | ||
Weight | PL9610 6Kg PL9611 6.5Kg |
