Home > Transportation > Tricycle & Parts > Electric Tricycle > PASSENGER TRICYCLE WITH ELECTRIC RAINBRUSH

PASSENGER TRICYCLE WITH ELECTRIC RAINBRUSH

PASSENGER TRICYCLE WITH ELECTRIC RAINBRUSH thumbnail-1
PASSENGER TRICYCLE WITH ELECTRIC RAINBRUSH photo-1
US$ 1,000 - 2,000 MOQ: 22 Units
Key Specifications
Get Latest Price
Use For:
Other, cargo and passenger
Driving Type:
Motorized
Displacement:
201 - 250cc
Contact Supplier Request Quote Chat Now
Chongqing Huajun Motor Tricycle Sales Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
ChongQing
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Use For Other, cargo and passenger
Driving Type Motorized
Displacement 201 - 250cc
Body Type Open
Certification Other, ISO9001:2008 and CCC
Brand Name Huajun
Place of Origin Chongqing, China
Model Number HJ
Size 3700mmx1350mmx1400mm



Huajun Motor Tricycle Manufacturing Co.,Ltd
Product Name PASSENGER TRICYCLE WITH ELECTRIC RAINBRUSH
FOB Price  1400.00USD--2,500.00 USD FOB  [Chongqing,China]  Port   {INCOTERMS2000}
Product  Technical  Specifications(General Information)
Part I
Technical Design		 Application Cargo&passengers Transport
Design Max Speed ≥60         km/h
Loading Capacity 500         kg
Unladen Kerb Weight 395         kg
Dimension(L*W*H) 3155x1250x1430  mm
Color Red/Green/Yellow/Black/Other colors
Track                          1050      mm
Wheel Base          2100      mm
Ground Clearance  160       mm
Brake Mode Front&Back wheels;Drum
Transmission Type Shaft Drive
Exhaust Pollution Subject to National Standard
Power 11.0        Kw
Cool Type Water Cooled
Min.Fuel Consumption 354g      kw.h
Fuel Type Gasoline
Fuel Tank Capacity 12/22     L
Part  II
Operation 		 Starting System Electric/Kick
Transmission  5 Forward &1 Reserse Gears
Gearshift Control  Manual-Foot
Clutch Method Manual-Hand
Brake Operate Mode Manual-Hand or Foot
Part III
Engine Details		 Engine Type Singlecylinder,4-stroke,camshaft downward
Bore Stroke 63.5×49.5mm
Fuel Type Gasoline
Compression Ratio 9.5:1
Rated Power&Rotating Speed 11.0KW /8000rpm
Max.Torgue/Rotating Speed 11.0N.m,6500rpm
Lowest No-Load  Speed Stability 1500rpm
Displacement(cc) 197ml
Ignition System CDI
Apply to  Motor tricycle
Starter Kick/Electric
Part  IV
Packing 		 Transport  By Land/Sea/Other
Port Of Loading  Chongqing/Shanghai/Other ports of china
Original Manufacturer HuaJun Motor Tricycle Manufacturing Co.,Ltd/China
Package Protective Packaging
Loading Capacity (CKD) 22 units in 20"GP,48Units in 40"HQ
Delivery Time (from loading port) 15-20 Days after receiving prepayment
Please Note:
*All sizes are approximate,any other sizes are available according to customers' special requests.
*For more optional details, please contact Huajun Motor Tricycle Manufacturing Co.,Ltd directly.
*Any details of the motor tricycle  should subject to our final confirmation before ordering.




PASSENGER TRICYCLE WITH ELECTRIC RAINBRUSH



PASSENGER TRICYCLE WITH ELECTRIC RAINBRUSH

Note: This model is not suit for oversea transport, pls consider this problem.
