LED Street Luminaries

LED Street Luminaries thumbnail-1
LED Street Luminaries photo-1
Negotiable MOQ: 20 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
LED Light Source:
Medium Type3
Input Voltage(V):
100vac-305vac
Lamp Power(W):
200
Contact Supplier Request Quote Chat Now
Wuxi Anbang Electric Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
LED Light Source Medium Type3
Input Voltage(V) 100vac-305vac
Lamp Power(W) 200
Lamp Luminous Flux(lm) 18000
Lamp Luminous Efficiency(lm/w) 83
Color Temperature(CCT) Cool White
Working Temperature(℃) 40, 70
Working Lifetime(Hour) 100000
Lamp Body Material Aluminum
IP Rating IP66
Certification EMC, UL
Warranty(Year) 3
Place of Origin Jiangsu, China
Brand Name Sunburst
Model Number LLD-009A
Cell Phone:15951517811
Tel:86-0510-85112999 ext 173
Fax:86-0510-85127000
Skype:wxthlw
yangjing(at) or anbangyangjing(at)
web:/en



Features

• Save 50-70% power consumption
• Latest technology on Hi-Flux LEDs (100,000 hours lifetime)
• Special secondary optical lens design to maximize light output & uniformity
• Surge Protection added as a necessary protection device for the electronics

• Easy adjustable mounting hardware for various mounting angles
• Retrofit of existing outdoor luminaires on parking lots, streets, storage sites, etc.
• Tool-less entry feature to allow for easy field maintenance
• Die cast aluminum enclosure to improve heat dissipation
• Environmentally friendly, eliminating light pollution
• Watertight & dustproof meeting IP66 standard



Parameters

Category

Parameter



Category

Parameter

LED No.

88/77/56pcs

Mounting Way

Mast Arm Mounting

Typical Mounting Height

8~12m

Voltage

100vac-305vac

Lighting Type

Medium, TypeⅢ

Power

200w/180w/140w

Light Efficiency

83lm/w

Operation Temp

-40℃~70℃

Total Flux

16600/15000/11620lm



Power Factor

0.95

Color Temp

4700-5300k



Life Time

>100,000hrs

Lighting Angle

75°x152°



Weight

12kgs

 LED Street LuminariesLED Street LuminariesLED Street LuminariesLED Street LuminariesLED Street Luminaries
