DZXJ 5L double planetary mixer,can make and design your kind

Specifications

China's leading double planetary mixer:
1. Can produce and design what you need.
2 has the function of mixing, cutting,etc.

product Description:

 The Double Planetary Mixer is new-type and mixing the device high-efficiently to innovate and improve by one developed out on the basis of digesting and assimilate foreign advanced technology, It from electrical machines, Moderating machine ,Framework,Seal and cover,planer frame rotates, agitator, Wall shaving device, Storage bucket, The hydraulic pressure of twin columns hoists or lower the device and so on make up.

 It is used for material viscosity is 1000-1000000cps, it is for easy mixer to complex mixer, for example: bond, silicone, solder paste, food industry , electronic and so on.

  main parameter:

Model  parameter		100L
Capacity (L)		100(φ500*500)
Revolution motor (kw/rpm)		7.5
Revolution speed(frequency control)(rpm)		0-60
Rotation speed (frequency control)(rpm)		0-75
Scraper speed(frequency control)(rpm)		0-63
Vacuum degree(Mpa)		-0.09
Lift-down step (mm)		300
Lift -down means(mm)		Twin column
Weight (Kg)		2000
size	Length (mm)	1940
	Width (mm)	650
	height(mm)	2200

packing and shiping :

We use the plywood case packing in general, but we would meet  your special requirements.

our service:

1 The warranty : any problem , expect for the artificial demage is in the scope of warranty service for 1 year.

 2 The engineer will be available for the maintain.

 3  If you need any training for operation, we will guide you.





Company Service:

Our company has a long history for almost 10 years, the engineer in our factory have excellent skill for making the machine, all the machine is made of high-quality parts, the after-sale service is best.
