New Technology Reactor Tank for Sale

New Technology Reactor Tank for Sale

Working Process

Through the electric heating pipes to heat conducting oil to the required temperature, and then the oil will transfer the heat to the materials in the reactor to start the reaction.
The temperature controller controls the thermal oil temperature and materials in the reactor, to achieve complete automation.

Agitator

Blade agitator, frame agitator, disperser, homogenizer, anchor agitator

Specification

Mixer type :homogenize, frame, anchor, axis
Material Quality:SUS304 or 316L
Appearance: mirror polished
Different size for your selection: 100L-6000L according to your need
Layer: three layer,two jacket.inner vessel, jacket and insulation with the configurations of agitator, CIP hole, Manhole, sight glass, thermometer
Type of Heating:Electric heating, steam heating, oil circulation heating, outside (inside) coil heating
Faction:Mixer,heating and keep warm,cooling,disperser,vacuum,homogenizer,lifting,sealing

Configurations

1.It is sealed type, and the material contacting the liquid is the stainless steel 304 or 316L
2.One set of totally enclosed blending plant
3.A self-rotating type cleaning
4.A set of air respirator, matching a 0.28pam folding filter element.
5.A set of liquid meter
6.A 0-100 thermometer
7.Manhole 450mm
8.A 100mm sight glass
9.A 036V light

Technical Parameters

Application

This stainless steel chemical reactor for paint, emulsion, adhesive, petroleum can be widely used in petroleum, chemical, rubber, pesticide, dye, medicine and food industry. Used to achieve curing, hydrogenation, alkylation, polymerization, condensation process.
Food procession, cosmetics production, chemical industry, dyeing and printing facilities, essence and fragrant substance production, fine chemical industry, emulsification of diesel oil and pitch.

Pictures

Trade

MOQ: 1 set Reactor Vessel

Packaging: Wooden cases or container for sea freight or according to the clients’ requirements.

Shipping: By sea, by air, express, according to customer's requirement.

Payment Term: L/C, T/T

Lead Time: 30 days after payment
