ZJR- 350L high quality homogenizer machine used in peanut butter food cosmetic
The 350L vacuum emulsifying mixer includes Main Tank,oil and water pot.Vacuum System,Stirring System, Homogenizer, Electric Lifting System,Electric Control Cabinet, Body Frame,Pipeline &Valves etc.
Technical parameters
Item |
350L vacuum emulsifying mixer |
|
|
Emulsifying pot |
Design Volume(L) |
350L |
Capacity(L) |
300 |
|
Scraper Stirring Power(kw) |
3.7 |
|
Scraper Stirring Speed(rpm) |
0-80 |
|
Homogenize power(kw) |
4 |
|
Electrical heating power(kw) |
12 |
|
Homogenize speed (rpm) |
2800 |
|
|
Water pot
|
Design Volume(L) |
250 |
Capacity(L) |
200 |
|
Stirring power(kw) |
0.75 |
|
Stirring speed(rpm) |
960 |
|
Electrical heating power(kw) |
12 |
|
|
Oil pot |
Design Volume (L) |
180 |
Capacity (L) |
150 |
|
Stirring power (kw) |
0.75 |
|
Stirring speed (rpm) |
960 |
|
Electrical heating power (kw) |
12 |
|
1. Mixing oil and water phases materials in high speed to get perfect emulsion product of good quality.
2. Machine consists of vacuum-resistant vessel with jacket for heating and cooling. Equipped with high speed homogenizer, scraping agitator, vacuum pump, and hydraulic pump for lifting, heating & cooling system.
3. With vacuum pump to take the air bubbles out of mixed product, and extend the time of storage.
4. Scraping unit is with moveable teflon scrapers to scrape off the materials on the tank wall and the anchor to move the materials to the center area to get better blending and mixing. The teflon scrapers are maintained manually and easily without any tool.
5. Our vacuum emulsifying equipment equipped with heating & cooling system which simplifies the processing. Within this same equipment, you can do from heating-melting-emulsifying-air bubble reduction(by vacuum)-cooling without changing vessels, it saves lot of labor and time for your production.
6. All contacted parts of equipments are SUS316L,the product homogenized in vacuum and close vessel can be sanitary and high quality.
7. The measuring of raw materials, the recording of temperature for heating, melting, emulsifying, cooling, and the change of mixing speed, and the vacuum suction can be controlled.
Vacuum Emulsifying Mixer Series
include: emulsification boiler(fluctuating nanhead, overturn boiler), water boiler, oil water, vacuum set, heating and temperature control systems, cooling systems, electric machinery control systems, ect.
Lifting,Mixing,Homogenizing,Dispersing,Heating,Cooling,Dosing,Vacuum,Pressure,Filter,Condensation,Distillation,Constant temperature control and so on.
Cosmetic Industry: Cream, Lotion, Lipstick, Shampoo;
Pharmaceutical Industry: Ointment, Syrup, Injection;
Food Industry: Mayonnaise, Dressing, Jam, Butter, Margarine;
Chemical Industry: Polyester, Synthetic Fiber.
Packing: wooden cases or container for sea freight or accoding to the clients requirements.
Shipping: European Countries: 22-28 days
United States: East --13-16 days, West--21-28 days
Brazil: 30-40 days
Russia: 36 days
Asia Countries: 3-5days
1. The equipment can be customized according to customer's material, in order to meet the needs of the process. Like high viscosity , strengthen the function of homogeneous, heat sensitive materials etc.
2. Interface way can choose (hoop, thread, and flange).
3. Material contact parts can choose SS 304, SS 316, SS316L, 2Cr13,9Cr18 etc.
4. Sealing material: Standard rubber ring is silicone rubber, according to the media requests; you can choose fluorine rubber, EPDM, PTFE
5. Frequency speed regulation, non frequency speed regulation, explosion proof design, non explosion proof design.
6. According to customer's workshop height, our engineers will be optimized to facilitate customer needs.
Warmly welcome to our factory to get more informations about our machines!
Factory address: Changdong Industrial Park, Chang'an Community, Yanqiao Street, Huishan Dist., Wuxi, Jiangsu, China (Mainland)
