construction design steel structure warehouse/steel frame warehouse
Item |
Description |
Size |
Width, height, length and roof slope |
Steel grade |
Q235B or Q345B carbon steel and alloy steel |
Column and Beam |
Hot rolled or high-frequency welding H-section steel |
Purlin |
hot galvanized C/Z section steel, size of C100-C320,Z160-Z300 |
Brace |
X or V or other type bracing made of angle steel, round bar |
Roof and wall |
EPS sandwich panel /FRP /colored corrugated steel plate
|
Door |
EPS sliding door / rolling up door / steel vertical hinged door
|
Windows |
PVC / aluminum alloy window / plastic steel window |
Connection |
Bolts/ welding / riveting |
Crane |
Usually as customer’s requirement, the maximum we can do is 200T or more |
Surface treatment |
Hot dip galvanized or painting |
Design software |
Auto CAD, PKPM, MTS, 3D3S |
Characteristics
a) Offer the integrated system solution from designing, manufacturing and installation
b) Excellent construction quality by meeting the standard requirement
c) Saving the investment with less foundation cost
d) Saving the time and labor effectively during the construction period
e) Using the environmental protection material with good quality
f) Saving the energy with excellent thermal insulation and heat dispersion properties
g) Excellent seismic behaviors, wind performance, rainproof and sealing performance
1. Load into 20/40GP, 40 HQ or 40OT, as customer's requirement
2. Shipped by sea
we are a comprehensive construction enterprise at offering the integrated system solution from designing to manufacturing, installation and maintenance. Our steelwork applies to the various uses of construction projects in the different fields and can meet fully the individual needs of various customers, such as industrial buildings, residential buildings, multiple floor buildings, long-swan space buildings and some other special steel structure.
Item |
Description |
Company name |
Luoyang Juya Engineering construction Co., Ltd |
Factory area |
25000 square meters |
Staff |
300+ |
Certification |
ISO9001 & ISO14001 & Safety in Production & Overseas Contracting Project Qualification |
Production capacity |
8000t/ year |
Product |
We can offer the integrated system solution from designing to manufacturing and installation |
Main production line |
1. Two lines for steel structure workshop, warehouse, shopping mall, exhibition hall series 2. One line for light steel structure villa 3. One line for large span space heavy structure, like bridge and tower |
Representative projects |
1. Material production workshop for Luoyang Refractory (Group) Co., LTD. 2. Production workshop for China Silicon Corporation Ltd. 3. Leather production factory for PT. LIPPO GROUP, Jakarta, Indonesia 4. Heat treatment workshop in Ghana, Africa. |
Transportation |
Loaded in 40’OT and 40’HQ |
Payment |
T/T 30% in order and T/T 70% before delivering the goods And the L/C is also available. |
1.Data for design:
*live load on roof(KN/M2), live load on second floor(KN/M2) if have
*wind speed(KM/H) or wind load(Kn/M2)
*snow load (Kn/M2) if have
*earthquake grade if have
*crane (if have): crane span, crane type, crane quantity, crane lift height, max lift capacity, max wheel pressure and min wheel pressure.
2.Type of the building
*dimension: width,length,eave height and roof slope
*single slope, double slope
*single-span,double-span or multi-span
*single-floor,double-floor or multi-floor
*whether gutter,rain pipe is needed or not
*Whether daylight bands,ventilators,parapet wall is needed or not
Production process and facility
