Help CenterTA2 2.2'' High Silicon Cast Iron Anode for Cathodic Protection
Related Products
-
4.8''X60'' HSCI Tubular Anode Made by Chinese ManufacturerUS$ 40 - 200MOQ: 30 Pieces -
4.8''X60'' Best Quality HSCI Tubular Anode for Cathodic Protection Made by Chinese ManufacturerUS$ 30 - 200MOQ: 20 Pieces
-
2.7''X84'' HSCI Tubular AnodeUS$ 25 - 150MOQ: 30 Pieces
-
2.7''X84'' HSCI Tubular AnodeUS$ 25 - 150MOQ: 30 Pieces
-
2.2''X84'' HSCI Tubular AnodeUS$ 25 - 150MOQ: 30 Pieces
High Silicon Casting Iron Tubular Cathodic Protection Anode
1.By chill cast & centrifugal cast, Center connection type
2.Compact and uniform crystal structure, High density, Low consumption rate, Long operating life
3.Conform to ASTM A518M or BS 1591:1975
Tubular Cast Iron Anodes
1/Specification:
Model |
O.D. mm (in) |
I.D. mm (in) |
Length mm (in) |
Nominal Area m2 (ft2) |
Nominal Weight kg (lb) |
HL-TC-1 |
56.0 (2.20) |
37.0 (1.46) |
2134 (84) |
0.375(4.04) |
21.0 (46.3) |
The dimensions above are nominal. HSCI tubular anodes can be customized in accordance with client's drawings and requirements.
2/Description:
HSCI tubular anode works well as deep well anode for cathodic protection of offshore platform, underground steel oil tube, underground cables, subsea pipelines, etc. It has high corrosion resistant capacity and high electrical conductivity, fully conforming to ASTM A 518M-99 Grade 3.
Their tubular design provides greater surface area over solid cast iron anodes of identical weight. This in turn lowers anode-to-earth resistance, decreases the current density on the surface of the anode and permits any generated gases to be distributed over a larger area. The tubular design also means the wire connection can be made in the center of the anode, thus eliminating the problem of end-effect consumption.
3/Chemical Composition(ASTM A 518M Gr3):
| Element | Content % |
| Silicon | 14.20-14.75 |
| Chromium | 3.25-5.00 |
| Manganese | 1.50 max |
| Carbon | 0.70-1.10 |
| Copper | 0.50 max |
| Molybdenum | 0.20 max |
| Iron | Remainder |
