All Kinds of Capacity High Voltage Ferrite Transformer

Name: All Kinds of Capacity High Voltage Ferrite Transformer
Brand: Huangshi
SKU: 120356225
Availability: InStock

Shenzhen Huangshi Machinery And Equipment Co., Ltd.

US$ 1 - 10,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Huangshi

Model Number:

HS-30030-LZL

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Huangshi

Model Number HS-30030-LZL

Usage Power

Phase Three

Coil Structure Other, autotransformer

Coil Number Autotransformer

Brand	Huangshi
Capacity	100VA-2000KVA
Frequency	50HZ/60HZ
Phase	Three
Input voltage	Rated voltage ±10%
Output voltage	Rated voltage ± 5%
Altitude	<1000m
Operation environment	Working temperature :-15 ℃ and 40 ℃ Humidity: 95%
Insulation standard	F grade
Wave distortion	No additional wave distortion
Primary voltage	380v 600v 400v 480v 220v 240v 415v( can be customized)
Output voltage	220v 120v 110v 230v 240v(can be customized)
Efficiency	≥ 95%
Production level	IP00, IP20
Cooling way	Dry winding cooling
Coil construction	Autotransformer/ Isolated transformer
All the input and output voltage, connection group and capacity of coil winding can be designed and produced according to users’ requirements.

The electrical transformers supplied by our company with those good advantages of small volume,

light weight, easy to maintain, reliable operation. Production strictlyconformed with the relevant IEC

international and GB national standards, applicable to various industries such as communication,

electric power, chemical industry,light industry, can be used as a lighting power supply, power supply,

etc, widelyused for imported or exported equipments, precision machine tools, machinery and electronics

equipment. The iron core is made of imported high quality silicon steel sheet, insulation standard up to

international H grade, conform with CE insulation system transformer connection cable is also very

convenient for connection, full of humanization design. low temperature rise, low operating temperature,

low mechanical hum ,low stray magnetic field,OEM & ODM is acceptable.

Model Number	HS-30100	HS-30150	HS-30200	HS-30300	HS-30450	HS-30600	HS-30750	HS-31000	HS-31500	HS-32000	HS-32500	HS-33000	HS-34000	HS-35000
Series	LZ series: Aluminum Autotransformer
	LG series: Aluminum Isolation
	TZ series: Copper Autotransformer
	TG series: Copper Isolation
Capacity(KVA)	10	15	20	30	45	60	75	100	150	200	250	300	400	500
Input Voltage	380V(Can design any voltage for you)
Output Voltage	220/220V(Can design any voltage for you)
Frequency	50HZ/60HZ
Load current (220v/hour)A	29	44	58	87	130	174	217	289	434	578	722	867	1155	1444
