Specifications
300mm Walking man Green LED Traffic LightCE&ROHS approved,IP65
2years guarantee,shell material:pc
Lifespan>50000h
ODM&OEM
300mm LED Traffic Light for Intelligent traffic system
Specification:
Description |
Typical |
Unit |
Input Voltage(VAC) |
AC200-240V |
Volt(AC) |
LED Type |
InGaN |
|
Color |
RED |
– |
Wave Length |
505NM |
nm |
No of LED |
120 | pcs |
Power Consumption |
12±1W |
Watt |
Connection |
Via 1.5m cable,2 core*0.5mm² |
– |
Relative Humidity |
20-95 |
% |
Operating Temperature |
0° To 70° |
Celsius |
Dimension(with front lens) |
299(D)*82(H) |
mm |
Lens Material |
UV-resist Polycarbonate |
– |
Weight(approx) |
1050 |
G |
IP Rating |
IP65 |
– |
Power Factor |
>0.85 |
PF |
Feature and Benefit:
- Excellent appearance & visibility
- High efficiency and high brightness LED light source, visual angle larger
- Up to 90% energy saving over incandescent
- Long life of 70,000 hours plus
- Exclusive optical lensing, good color unifoumity
- Multi-ply sealed, water & dust resistant
- Up to national standard GB-14887-2003
- Reduce overall operating & mainenance costs:Energy saving:90% reduction in power consumption vs incandescent
- Reliability & traffic safety:Improve visibility over life of the product Reduces emergency lamps outs Design minimizes sun phantom effects
- Easy to install into existing signal enclosure
Our advantages:
1.We produce the Diode by ourselves,Quality is well controlled.
2.Professional factory with high quality & competitive price.
3. We can supply OEM, ODM service and protect all of your design and your private information
4. All the shape, size, color, brightness is available here
5. We supply technical support, so you can call our engineer anytime
6. Delivery on time & satisfactory after-sales service
Package:
Trade Terms
1 payment: T/T, Western Union
2 Production lead time for 100-500pcs: 10 days, 500-10000pcs: 15 days
3 Sample can be delivered in 3days
4 Shipping freight are quoted under your requests
5 Shipping port: Shenzhen, Mainland China
6 Discounts are offered bassed on order quantityes
About us:
ShenZhen TongDa Opto-Electronic co.,ltd, founded in Year 2001, specializes in developing ,manufacturing and selling LED light source and LED lighting products.The company consists of 2 main departments :single LED manufacture Dept & LED lamps Dept . Also it has a strong R & D team, high efficient management mode, top after-sale service ,and so many automatic production equipment ,such as : Dispenser Machine,LED Die bonder, Gold wire bonder, LED packaging machine, LED testing machine,and LED sorting &spectral color separation machine.
Service
1. Quick reply to the customer's inquiry with 24hrs
2. We can do OEM for all our product lines, e.g. buyer's logo and design service etc.
3. Customized service available
4. Special discount if substantial order is placed
