Help Center300mm Green Man LED Traffic Sigal Light
Related Products
-
200mm RYG Cobweb Lens LED Traffic LightNegotiableMOQ: 100 Pieces -
IP65 High Quality 300mm Red Yellow Green Color Led Traffic Singal LightUS$ 40 - 50MOQ: 50 Pieces
-
300mm Yellow Cobweb Lens LED Traffic LightNegotiableMOQ: 100 Pieces
-
200mm Yellow Cobweb Lens LED Traffic LightNegotiableMOQ: 100 Pieces
-
200mm Full Circle Red LED Traffic LightNegotiableMOQ: 100 Pieces
Specifications
1.Color:green2.Housing Material:PC
3.IP Rating:IP55
4.Green products
Specification:
Description |
Typical |
Unit |
Input Voltage |
200-240 |
Volt(AC) |
Wave Length |
505 |
nm |
LED Type |
– |
– |
No of LED |
120 |
pcs |
Power Consumption |
7.5±1W |
Watt |
Connection |
Via 1.5m cable,2 core*0.5mm² |
– |
Relative Humidity |
20-75 |
% |
Operating Temperature |
0° To 70° |
Celsius |
Dimension(with front lens) |
299*82 |
mm |
Lens Material |
UV-resist Polycarbonate |
– |
Weight(approx) |
1010 |
G |
IP Rating |
IP55 |
– |
power factor |
0.94 |
PF |
Feature and Benefit:
1.Excellent appearance & visibility
2.High efficiency and high brightness LED light source, visual angle larger
3.Up to 90% energy saving over incandescent
4.Long life of 70,000 hours plus
5.Exclusive optical lensing, good color unifoumity
6.Multi-ply sealed, water & dust resistant
7.Up to national standard GB-14887-2003
8.Reduce overall operating & mainenance costs:Energy saving:90% reduction in power consumption vs incandescent
9.Reliability & traffic safety:Improve visibility over life of the product Reduces emergency lamps outs Design minimizes sun phantom effects
10.Easy to install into existing signal enclosure
About us:
ShenZhen TongDa OptoElectronic co.,ltd, founded in Year 2001, specializes in developing ,manufacturing
and selling LEDlight source and LED lighting products.The company consists of 2 main departments :
single LED manufacture Dept & LED lamps Dept . Also it has a strong R & D team, high efficient management
mode, top aftersale service ,and so many automatic production equipment ,such as : Dispenser Machine,
LED Die bonder, Gold wire bonder, LED packaging machine, LED testing machine,and LED sorting &spectral
color separation machine.
Our Service:
1 Reply your enquiry in 24 working hours.
2 Experienced staffs answer all your questions in fluent English.
3 Customized design is available. OEM&ODM are welcomed.
4 Exclusive and unique solution can be provided to our customer
by our well-trained and professional engineers and staffs.
5 Special discount and protection of sales area provided to our distributor.
Trade Terms:
1. Payment: By T/T or Western Union .
30% deposit and 70% balance before shipment
2. Lead time: 5~10 working days, subject to the order quantity
3. Delivery ways: DHL, UPS door to door service, by sea, by air, etc.
4. MOQ: 100 PC
