Place of Origin
Guangdong, China
Brand Name
SANKE, SAKO, SAK, OEM
Model Number
PCN-V
Specifications
PCN-V series UPS adopts advanced technology of micro-processor control and digital LCD display. The power voltage scope as 140V-CPU control
Wide Input Voltage Range
Wide Input Frequency Range
High/Low Voltage Protection, Overload/Short Protection
Cool start computer even there isnt main power
Automatic recharge even UPS is off
Automatic restart
Beeping Alarm on Battery, Battery Low and Overload
Beeping Selection
Intelligent Battery Management
Intelligent LCD Display
Smart RS232 & RJ11& USB Option
Compatibility with generators
| Product | Requirements | Model 1 | Model 2 | Model 3 | Model 4 | Model 5 |
| Power (VA) | PCN-V500 | PCN-V650 | PCN-V1000 | PCN-V1500 | PCN-V2000 | |
| Input | Voltage | 145-290VAC±5V | ||||
| Frequency | 50Hz+/-10% | |||||
| Output | Voltage (AC Mode) | 190-250VAC | ||||
| Voltage (Inverter Mode) | 220VAC ±5% | |||||
| Capacity | 500VA/300W | 650VA/360W | 1000VA/600W | 1500VA/880W | 2000VA/1100W | |
| Frequency (Inverter Mode) | 50Hz+/-0.5Hz | |||||
| Transfer Time | 2ms typical | |||||
| Generator connection | Normal Working under the Generator | |||||
| Waveform | modified-Sinewave | |||||
| Protection | Spike & Surge Suppression | yes | ||||
| Over/Under Volt. | Switch to Bat. O / P when Mains over regulation range | |||||
| Over load /short Circuit | Fuse & current linited for both Mains and Battery modes | |||||
| Battery | Type | Lead-Acid miantenance-free | ||||
| Dc Bus | 12V7.0Ah | 12V7.0Ah | 12V9.0Ah | 12V7.0Ah | ||
| Number | 1 PC | 2 PCS | 3 PCS | |||
| Recharge time | 8hours≥90% | |||||
| Back up time(one PC) | 8-15mins | 10-18mins | 20-30mins | 25-45mins | 30-45mins | |
| Physical | Weight (KGs) | 5 | 5.5 | 10.5 | 11.5 | 17 |
| Shipping Wt. | 5.6 | 6 | 11 | 12 | 17.5 | |
| Product Dimensions (mm) | 335*95*160 | 355*120*195 | 410*145*215 | |||
| Packing Dimensions (mm) | 375*170*200 | 420*190*250 | 480*235*320 | |||
| Soft ware | RS232 or USB option Windows & NT | Auto save & shut down | ||||
| Function | Cold start | UPS Start The Computer Even there Is no Main Power | ||||
| Automatic Charge | Automatic Charge when UPS is off | |||||
| Automatic Restart | Automatic Restart if main power coming within one hour | |||||
| Voltage display | 220v/230v Optional following the real capacity | |||||
| Frequency | 50HZ/60HZ Optioanl following the real | |||||
| Beeping | During the battery mode ,the beeping optional | |||||
| Efficiency | AC-AC | 1 | ||||
| DC-AC | 0.6 | |||||
| Acoustic | Noise level | ≤45dB | ||||
| Environmental | Temperature | -5-45 DegreeC | ||||
| Humidity | 20% to 90% | |||||
| Power Outlets | No. and types | 2 SOCKETS | 3 SOCKETS | 4 SOCKETS | ||
