Home > Products > Wire Drawing Pulley > Zirconia guide pulleys/ceramic U grooved wire drawing pulley
Zirconia guide pulleys/ceramic U grooved wire drawing pulley
USD $999 - $999
/ Piece
1 Piece(Min.Order)
- 10000 Piece / Pieces per Month
- Shenzhen
- T/T Credit Card PayPal
You May Like
-
Manufacturer's direct sales cone sleeve European standard pulley V-belt pulley non-standard pulley drive wheel
-
Toothed pulley 5m main motor synchronous NC pulley 5m NC spindle motor pulley BT30
-
CNC turning parts with high precision customized timing pulley as drawings
-
Bridge customized oem cnc machining sand casting rope pulleys, aluminum timing belt pulley
-
zinc plating u shape rope groove pulley v belt pulley 608zz
-
Small Zinc Blue / Stainless steel with eye sheave pulley cap 850 LB 386 kg
Product Details
| Material: | Zirconia ceramic | Brand: | AV | Model: | AV-1012027 |
Product Description
Specifications
1,Zirconia guide pulley2,Ceramic wire drawing rings
3,Mirro polishing
4,High hardness; wear/corrosion resist
5,ODM
| Type | Drawbench guide pulley |
| Pulley material | Zirconia Ceramic |
| Forming method: | Sintering |
| Dimension | Customized/ODM |
| Working surface | Fine polishing |
| Application | For ferrous/nonferrous, fiber wire drawing. |
| Feature | High hardness, good wear/corrosion resistance, etc. |
| well thermal endurance, excellent polishability,etc. | |
| Serve Life | Durable |
| Sample | Yes |
| Place of origin | China |
| CERAMIC PROPERTIES: | |
| * Outstanding hardness/ strength | |
| * Well Surface Finish | |
| * High Corrosion Resistance | |
| * High fracture toughness | |
| * Low coefficient of thermal expansion | |
| * Low heat conductivity | |
| CERAMIC PERFORMANCE PARAMETER: | |
| Density: 3.6-3.7 g/cm3 | |
| Bending strength: 300-400 Mpa | |
| Fracture toughness: 4-5 Mpa.m1/2 | |
| Hardness: ≥86 HRA | |
| Modulus of elasticity: 320-390 Gpa | |
| Coefficient of linear expansion: 6.5-11.2 x10-6/k | |
| Minimal residual unbalance of up to: ≤0.8 Gmm/kg | |
| Unbalance reduction rate: ≥85% | |
| Here We supply wire drawing pulleys: Cones, Guides pulleys, Rings, Rollers, multi grooved rollers, etc. Spraying material: Chrome oxide ceramic, Tungsten carbide, etc. Sintering material: Zirconia ceramic, Alumina ceramic, etc. To offer you the most suitable pulleys, kindly advise the following info: 1, Your drawing/design? 2, Pulley material? 3, Wire material? 4, Qty for each size? 5, Wire machine's brand? 6, Other requirements?(e.g.: polishing grade, hardness, etc.) Thank you for your time! | |
