Wire Drawing Zirconia Rings/assembled Cone Pulley/combination Stepped Capstan

US$ 18.9 - 389.9 MOQ: 4 Sets

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Model Number:

26001

Shenzhen Apple Vista Technology Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name AV

Model Number 26001

Specifications

1.Wire drawing zirconia rings
2.High hardness/strength
3.Wear/corrosion resisting
4.Fine surface polishing
5.Customized

Type	Assembled wire drawing cone pulley
Pulley material	Zirconia ceramic
Forming method	Sintering
Structure:	Steel
Dimension	Customized/ODM
Working surface	Fine polishing
Application	For ferrous/nonferrous, fiber wire drawing.
Feature	High hardness, good wear/corrosion resistance,
	well thermal endurance, excellent polishability,etc.
Serve Life	Durable
Sample	Yes
Place of origin	China

CERAMIC PROPERTIES:
* Outstanding hardness/ strength
* Well Surface Finish
* High Corrosion Resistance
* High fracture toughness
* Low coefficient of thermal expansion
* Low heat conductivity

ZIRCONIA CERAMIC PERFORMANCE PARAMETER FOR REFERENCE:
Density: 5.5-6.05 g/cm3
Bending strength: 1100 Mpa
Fracture toughness: 12 Mpa.m1/2
Hardness: 88-90 HRA
Modulus of elasticity: 220 Gpa
Coefficient of linear expansion: 6.5-11.2 x10-6/k
Minimal residual unbalance of up to: ≤0.8 Gmm/kg
Unbalance reduction rate: ≥85%

Here We supply wire drawing pulleys: Cones, Guides pulleys, Rings, Rollers, multi grooved rollers, etc. Spraying material: Chrome oxide ceramic, Tungsten carbide, etc. Sintering material: Zirconia ceramic, Alumina ceramic, etc. To offer you the most suitable pulleys, kindly advise the following info: 1, Your drawing/design? 2, Pulley material? 3, Wire material? 4, Qty for each size? 5, Wire machine's brand? 6, Other requirements?(e.g.: polishing grade, hardness, etc.) Thank you for your time!
