Specifications
wire drawing cone pulley with ceramic coating1.Wire cable guide capstan
2.High hardness
3.Corrosion resist
4.Fast deliver
Wire drawing capstan pulley with spraying tungsten carbide ceramic
Material: WC Metal-ceramic
Thickness of Coating:0.2-0.3mm for single side after grinding.
Craft :Detonation Spraying
Hardness of coating : Hv 1300 (HRC 65 ° above )
Surface porosity :< 1%
Surface bonding strength : > 89-90 Mpa
Surface roughness : 0.2-0.4
1High strength and fracture toughness
2High hardness and wear resistance
3its coefficient of thermal expansion almost attain the common metal
Hardness
Specially formulated, zirconia ceramic is the most man-made material for wear applications such as wire drawing capstans.
Corrosion Resistance
Specially formulated, zirconia ceramic is highly resistance to attack by corrosion problems(chemical contents used in processing of wire drawing).
The corrosion resistance fo zirconia ceramic is far superior to metal.
Surface Finish
The superior surface by high polish processing result in high quality of the drawn wire plus extended die life.
Originality
Providing excellent hardness, corrosion resistance, superior surface finish, ceramic capstans attained worldwide estimation in wire drawing industries field.
pulley paramcter | |||||||||||
NO. |
item |
unit |
materials |
||||||||
A-95 |
A-97 |
A-99 |
ZTA |
ZRO2 |
|||||||
1 |
density |
|
3.6 |
3.65 |
3.7 |
4.0-4.3 |
5.5-6.05 |
||||
2 |
bending strength |
Mpa |
300 |
350 |
400 |
700 |
1100 |
||||
3 |
fracture toughness |
|
4 |
4.5 |
5 |
7 |
12 |
||||
4 |
Hardness |
HRA |
≥86 |
≥88 |
≥89 |
≥90 |
88-90 |
||||
Modulus of elasticity |
GPa |
320 |
350 |
390 |
300 |
220 |
|||||
5 |
coefficient of linear expansion |
|
6.5-11.2 |
||||||||
6 |
Minimal residual unbalance of up to |
Gmm/kg |
≤0.8 |
||||||||
7 |
unbalance reduction rate |
|
≥85% |
||||||||
Any question,pls contact me freely via cell phone: 86+188 1682 8120
