Home Inverter System With Modified Sine Wave

Home Inverter System With Modified Sine Wave thumbnail-1
Home Inverter System With Modified Sine Wave photo-1
US$ 250 - 600 MOQ: 50 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
SAKO or OEM brand
Model Number:
SLH500-2000VA
Contact Supplier Request Quote Chat Now
Sako Electrical Group Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name SAKO or OEM brand
Model Number SLH500-2000VA
Input Voltage 90-270V
Output Voltage 220V
Output Power 300W,600W,1200W
Output Frequency 50HZ,60HZ

Specifications

1.Wide Input Voltage Range (With AC Charger)
2.Large Charge Current Even Input Voltage Is Low
3.Automatic Charge While AC Reco

0, 0, 7, 0, 0, 269, 8, 19
SAKO SLH SERIES TECHNICAL PARAMETER
MODEL SLH-500VA SLH-1000VA SLH-2000VA
SPECIFICATION
  AC BYPASS (With AC Model)
Input AC Voltage (VAC) 220VAC
Input AC Range (VAC) 90VAC-270VAC
Input Frequency Range (Hz) Same As Input Frequency
Input Current (A) 1.36A 3.63A 7.27A
Charge Current (A) 10A (20A Optional)
Transfer Time (ms) <= 20ms
Output Voltage Same As Input Voltage
  BATTERY
Battery Built Inside 12V/65AH 12V/100AH 12V/100AH*2
Battery Type Maintenance Free Lead Acid Battery
Over Charge Protected Voltage (VDC) 14.5V±0.2V 14.5V±0.2V 29V±0.2V
Over Charge Back Voltage (VDC) 13.2V 13.2V 26.4V±0.2V
Over Discharge Protected Voltage (VDC) 10.5V±0.4V 10.5V±0.4V 21V±0.2V
  OUTPUT (In Battery Model)
Output Power (W) 300 600 1200
Output Voltage (VAC) AC 220V±10% (In Battery Model)
Output Frequency (Hz) 50Hz±1% (In Battery Model)
Output Wave Form Modify Sine Wave
Overload & Shortage Protection Yes
Output Overload Capacity Over Load 120%,60s, Later Shut Over
By Pass Transfer Time (ms) <= 20ms
  PROTECTION
Protection Over load/ over voltage/ low battery/ low voltage/ Input low/ hight voltage/ short current Protection
  AMBIENT
Noise (Db) < 50dB (1 Meter)
Working Temperature -20°C to 50°C
Humidity 0~95% (No Condensation)
Sea Level (m) <= 1500m
  DIMENSION
L×W×H (Products Size) (mm) 500*220*338 mm 500*220*338 mm 510*372.5*460 mm
L×W×H (Package Size) (mm) 597*310*479 mm 597*310*479 mm 587*472*502 mm
Weight (N.W. Kg) 41 Kg 45 Kg 79.6 Kg
Weight (G.W. Kg) 43 Kg 47 Kg 98 Kg
20Ft Qty (Unit) 300 300 165


 Home Inverter system with modified sine waveHome Inverter system with modified sine wave





Home Inverter system with modified sine wave

Home Inverter system with modified sine wave

Home Inverter system with modified sine waveHome Inverter system with modified sine waveHome Inverter system with modified sine wave





Home Inverter system with modified sine wave

Home Inverter system with modified sine waveHome Inverter system with modified sine waveHome Inverter system with modified sine waveHome Inverter system with modified sine waveHome Inverter system with modified sine waveHome Inverter system with modified sine wave
