Specifications
Anilox rollers1.High corrosion resistance
2.Excellent wear resistance
3.Specially formulated
4.Long woking life
Ceramic Printing Anilox Rollers
Specifications and Parameters:
1. Screen count range : 80-2000 LPI
2. Maximum width : 3800mm 4250mm ( with axis)
3. Diameter range :25-500 mm
4. Screen angle : 1-89 degree
5. Cell shape : hexagon , quadrangle and line , etc and the many morn cell shapes may meet your requirement .
Main Features:
1. Anti-fraying , Anti-corrosive , Thermostability, Long-life service and cost-sacing .
2. The cell engraved by ALE fiber laser engraving machine , has a large quantity of ink-containing .
And the cell has a regular shape and a smooth cell-wall and cell-bottom . Thus , not only can the ink in the cell release quickly , but also it can easily to clean .
3. Taking strict process of plasma-sprayed ceramic layer , guarantees the porosity , the thickness and the uniformity of the layer .
4. Combined with the super-alloy stainless steel layer to ensure the solid combination of the ceramic layer and the roller base . So , it can present the corrosive substance of the printing ink to plug into the roller base effectively .
5. Providing all the products the cell-volume detecting report to ensure the accuracy of the cell’s ink-containing .
Processing Flow:
Based-roller Processing → Sandblasting Treatment → Nickel-chromium Alloy Coating →
Chromium Oxide Ceramic Layer → Carborundum Grinding → Carborundum Polishing
→Laser Engraving → Polishing and Cleaning
Application:
1. Flexographic Printing, Lithography Printing , Gravure Printing
2 .Flexible Packing
3. Label , Envelope , Paper Forms , Handbag
4. Corrugated Box
5. Plastic Film, Coated Paper Products, Glazing
6.Wallpapers , Wooden-patterned Paper , etc .
