Nuts Stand-up Filling Sealing Machine

Name: Nuts Stand-up Filling Sealing Machine
Brand: ECHO
SKU: 120271589

US$ 20,000 - 40,000 MOQ: 1 Set

Key Specifications

Condition:

New

Application:

Beverage, Chemical, Commodity, Food, Other, Medical, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Medical

Packaging Type:

Bags, Film, Pouch, Stand-up Pouch

Wenzhou Echo Import & Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

port of china

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Application Beverage, Chemical, Commodity, Food, Other, Medical, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Medical

Packaging Type Bags, Film, Pouch, Stand-up Pouch

Packaging Material Plastic

Automatic Grade Automatic

Driven Type Pneumatic

Voltage 380V 50HZ 3P

Power 2kw

Place of Origin Zhejiang, China

Brand Name ECHO

Model Number MR8-200

Weight 1200kgs

Dimension(L*W*H) 1645*1900*1455MM(L*W*H)

Certification CE, CE,ISO9001,Utility Model Patent Certificate

After-sales Service Provided Overseas third-party support available

Technical Parameters

Model	MR8-200	MR6-200	MR6-300
Working station	EIGHT	SIX	SIX
Function (Station can customize made according the packing details )	Bag feeding, Date printing, Bag opening, Filling 1, Filling 2, Sealing 1, Sealing 2, Outputting	Bag feeding, Date printing, Bag opening, Filling, Sealing, Outputting.	Bag feeding, Date printing, Bag opening, Filling, Sealing, Outputting.
Packing material	Laminated film pre-made bag	Laminated film pre-made bag	Laminated film pre-made bag
Bag size	80-200mm(W) 100-300mm(L)	80-200mm(W) 100-300mm(L)	200-300mm(W) 100-350mm(L)
Weight	1200KGS	1000KGS	1400KGS
Filling volume	5-2500G	5-2500G	5-2500G
Speed	25-60 per/min for common bag 8-30 per/min for zipper bag (The speed depends on the product status and filling weight)	25-50 per/min for common bag 8-30 per/min for zipper bag (The speed depends on the product status and filling weight)	25-50 per/min for common bag 8-30 per/min for zipper bag (The speed depends on the product status and filling weight)
Total power	2kw	1.5kw	3kw
Dimension	164013401500mm	154012401465mm	1647014501560mm
Compress air requirement	0.6m ³/min Supply by user	0.6m ³/min Supply by user	0.6m ³/min Supply by user
