Supermarket Electronic Barcode Scale / Hot Sell Scale !

Supermarket Electronic Barcode Scale / Hot Sell Scale ! thumbnail-1
Supermarket Electronic Barcode Scale / Hot Sell Scale ! photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
GSAN
Model Number:
TM-Aa6a
Contact Supplier Request Quote Chat Now
Guangzhou City Gsan Science & Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
guangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name GSAN
Model Number TM-Aa6a

Specifications

1.Electronic barcode scale,with thermal printer with software.
2.max.4000 PLU storage, Max weight 30kgs.

Hot sell ! Electronic barcode scale .Most popular use in supermarket and retail shop !





Features:



Large storage:

max.4000 PLU

Various properties of PLU:

Max.3 lines of article name, max, 3 lines of advertising info. POS code. Unite price, Mac 4

Discount period and discount rate, etc.

Can store max 16 label formats, each PLC can quote different label format in the 16 formats library

Advertising Info

Can store max. 22 pieces advertising info

Free text

Can store 32 pieces free text

Store 142 short-cut-key, easy to operate

Powerful management software, high speed uploading or downloading

Support various format of PLU backup text files transfer make it possible to work with other scales or software

Friendly interface of the management software lead to logical and reasonable operation

Technical Data

Resolution

3000

Temperature

Storage: -10 to 55 degree

Work: -10 to 40 degree

Label and continue paper printing

Large storage with Max4000 PLU, 31 or 71 short-cut-key

Communication interface:        RS232 <standard ethernet (option)>

All function can be set on the scale

Easy to set label format and other details through the software

Manually and automatically printing inventory and report forms printing

Port to connect with cash drawer ( option)

Can work together with other scales and software

Format label format can be used or label format can be freely designed

Specification

Capacity

3kg

6kg

15kg

30kg

Division

1g

2g

5g

10g

Precision

1/3000

1/3000

1/3000

1/3000

Minimum

20g

40g

100g

200g

Dimension

(L*W*H)

361*388*160mm (bench type)

381*428*500mm (pole type)



Specifications:

Resolution

203DPI (8 dot/mm )

Print Mode

Thermal Transfer/ Direct thermal

CPU

32 Bit

Memory

4 MB Flash, BMB SDRAM

Print Speed

2IPS-4IPS

Print Length

Min 12mm (0.47”)Max*1727mm(68”)

Print Width

108mm(4.25“)

Sensor Detection

Type: Label gap and black mark sensing,

Detection: Label length auto sensing and

Program command setting

Media

Label Roll OD,Max,125mm(4.64”)

Core Diamerer:1”,1.5”,3”.

Width:25mm (1”)-118mm(4.64”).

Thickness:0.06mm-0.25mm(0.0025”-0.0098”)



Ribbon

Length:300M(981 ft);

Max. Ribbon roll OD:68 mm(2.67”)

Ribbon width:30mm-110mm(1.88” to 4.33”),

Coating: outside only, Core inner

Diameter

25.4(1”)

Printer language

EZPL(Firmware downloadable)

Software

Application: Qlabel-IV(EZPL only),DLL&

Driver: Microsoft windows NT 4.0,2000,XP and Vista

Resident Fonts

11 resident alphanumeric fonts (included OCR A&B),those are expandable 8 times horizontally and vertically. All bit mapped fonts 8. orientations.

Scalable font (code page 850&852) in 4 orientations.

Fonts Download

Windows bit mapped in 8 orientations.

True Type font (Ver.2XX) and Asian fonts in

4 orientations

Image Handing

BMP, PCX, Support ICO,WMF,JPG,EMF file

Through software

Barcodes

Code39,code93,code128(subset A,B,C),UCC/EAN-128K-Mart,UCC/EAN-128,

UPC A/E (add on 2&5),12 of 5,12of 5 with shipping bearer bars, EAN 8/13(add on 2&5),Codabar, Post NET,EAN 128,DUN 14

Maxi code, HIBC, Plessey, Random weight, Tele pen, FIM, China postal code

RPS128,PDF417,Datamatrix code & QR code

Interface serial port:

RS-232(baud rate:4800-115200.Xon/Xoff,

DSR/STR);USB port: V2.0; Parallel port: Bi-direction

Control panel:

Two multiple-color LED lights, Ready, Status, Function key, FEED

Power

Auto Switching 100/240 VAC,50/60 HZ

Environment

Operation:40 F to 104 F(5 to 40degree)

Storage: -4 F to 122 F (-20 to 50degree)

Humidity

Operation:30-85%,non-condensing ,free air,

Storage: 10-90%,non-condensing,free air

Cert .Approval

CE, FCC, Class A, CCC,CB,CUL,BSMI

Print dimension

Length:

285mm(11.2”)

Height

171mm(6.8”)

Width:

226mm(8.9”)

Weight

2.72kgs

Options

Rotary cutter module, stripper module ,

Compact flash (CF) card socket with real time dock (RTC), internal ethernet adapter card

Packing

USB cable, power card ,parallel cable, ribbon

Ribbon shaft(1” core),empty ribbon core,

Label, label roll core, CD, quick start guide,

Cleaning car



Supermarket electronic barcode scale / hot sell Scale !Supermarket electronic barcode scale / hot sell Scale !
