KH400 rotary drilling underground diaphragm wall grab

Specifications

diaphragm wall grab
1. Easy to opeation and maintaning;
2.Multifunction & High efficience;
3. high reliable & stable qualit



Product name

KH400 underground rotary drilling diaphragm wall grab

Specifications

1.High working stability
2.Higher efficiency, low noise, low emission
3.Powerful performance



Features



Performance Parameter
Groove width	400~800mm
Groove length	3500mm
Depth of the groove	60m(decided by the crawler cranes)
Grab weight	9.8~11.1t
Excavation volume	0.8~1.6m³
Excavators weight	2~3t
Crawler cranes requirements	≥40t and line pull above 200KN, main arm lifting height above 25m



Brief introduction

1. Underground diaphragm wall grab grooving machine is a conventional underground continuous operation trenching equipment .

2.  Its device can be operated by using the crawler crane equipment , achieved the international concept of "multi-function machine".

3. The working device is pure mechanical structure, with simple structure, easy to operate, and easy to maintain. Equipped with our professional designed grab bucket, single bucket capacity up to 1.3 cubic meters, greatly improve working efficiency.

4. This equipment’s groove width is 400-600mm, the maximum groove depth can extent to 150 meters, is the ideal choice of conventional underground construction slot devices.



Pictures





About company

Xuzhou Reman Construction Machinery Remanufacture Co., Ltd is located in xuzhou, the earliest place to research and development, production base of rotary drilling rigs in China. The company is specialized in selling new rotary drilling rigs, full -rotary drilling rigs and other piling machine; has complete industrial chain of researching and development, manufacturing and marketing various buckets, supply spare parts; also engages in evaluating and trading second-hand rotary drilling rigs .
