Product Name
XZ680A Horizontal Directional Drill Construction Machinery
Product Introduction
XZ Series Horizontal Directional Drills are mainly used in the trenchless piping construction and replacement of the underground pipe. The XZ Series Horizontal Directional Drills have the advantages of advanced performance, high efficiency and comfortable operation. Many key components adopt international famous products to guarantee the quality. They are the ideal machines for the construction of the water piping, gas piping, electricity, telecommunication, heating system, crude oil industry.
Product Advantage
1. Wire controlling self-propelled steel track makes transferring convenient .
2. Cummins turbo charging engine offers powerful thrusting force .
3. Equipped with efficient advanced load sensitivity, electro-hydraulic proportion control, imported hydraulic parts, and independent heat dissipation system .
4. Spindle rotation and rack-and-pinion carriage drive .
5. Assistant crane saves labor and makes work efficient.
6. Climate-controlled cab with monitor makes comfortable condition.
7. Chassis and carriage are mutual locked to protect device along with monitors of engine and hydraulic system.
8. Manual operation system is prepared for emergencies.
Product Main Technical Data
| Model | XZ680A | |
| Engine | CUMMINS | |
| Rated power | kW | 239 |
| Push-pull | Rack and pinion | |
| Max.pullback/thrusting | kN | 725/725 |
| Spindle torque(max) | N.m | 28000 |
| Spindle speed | r/min | 0-100 |
| Travelling speed of power head | m/min | 0-32 |
| Backreaming diameter | mm | Ø1000 |
| Pipe length(single) | m | 6 |
| Pipe diameter | mm | Ø102 |
| Entry angle | . | 10-18 |
| Mud flow rate(max) | L/min | 600 |
| Mud pressure(max) | bar | 100 |
| Overall weight | T | 21 |
| Dimension(L×W×H) | mm | 11610×2475×3115 |
Xuzhou Reman Construction Machinery Remanufacture Co., Ltd is located in xuzhou, the earliest place to research and development, production base of rotary drilling rigs in China. The company is specialized in selling new rotary drilling rigs, full -rotary drilling rigs and other piling machine; has complete industrial chain of researching and development, manufacturing and marketing various buckets, supply spare parts; also engages in evaluating and trading second-hand rotary drilling rigs.
Xuzhou Reman Construction Machinery Remanufacture Co., Ltd has many year's technical advantages, professional and experienced maintenance team; with moving maintenance shop--special vehicle for rigs field service; and advanced testing equipment, professional repairing workshop, spare parts warehouse, perfect testing methods and management system, all of these ensure the quality of our service and woke efficiency.
