Product Name
JD110A Crawler Mounted Hydraulic Anchor Drilling Rig
Product Introduction
Anchor drilling rig is designed for anchor supporting, mainly used for open mining exploitation, infrastructure drilling, rock drilling in irrigation works, electric station, construction material, transport & national defense construction, with unusual advantages in the harnessing & preventing of pit collapse, slope slide, geologic hazards, etc.
Product Specification
| Total Weight | kg | Appx.11000 | |||
| Engine | Model | Cummins6CAT5.9 | |||
| Output | kW | 110 | |||
| Hydraulics | Pressure | Mpa | 20 | ||
| Hydraulic tank capacity | L | 460 | |||
| Drifter | HB50A(krupp of Germany) |
||||
| Rotary mechanism | Pressure | Mpa | 25 | ||
| Flow rate | L/min | 170 | |||
| Max. speed | r/min | 80 | |||
| Max. torque | N.m | 130000 | |||
| Percussive machanism | Percussive frequency | min-1 | 1200 | 1900 | 2500 |
| Percussive torque | Nm | 590 | 400 | 340 | |
| Impulsion force | Kn | 53 | |||
| Extraction force | Kn | 71 | |||
| Max. impulsion speed | m/min | 40.8 | |||
| Max. extraction speed | m/min | 39.6 | |||
| Feed stroke | mm | 4100 | |||
| 27º | |||||
| Traveling speed | km/h | 3.08 | |||
Product Advantage
1. Adopts hydraulic transmission, enegry saving, high efficiency, low noise & low cost .
2. High temperature,high pressure,high wear resistance .
3. The unique design for the pump group make it convenient maintenance, and reduce maintenance cost .
4. Equipped with high or medium pressure air compressor with high speed hole drilling ability.
5. According to the function layout, install valve, handles, convenient operation.
Xuzhou Reman Construction Machinery Remanufacture Co., Ltd is located in xuzhou, the earliest place to research and development, production base of rotary drilling rigs in China. The company is specialized in selling new rotary drilling rigs, full -rotary drilling rigs and other piling machine; has complete industrial chain of researching and development, manufacturing and marketing various buckets, supply spare parts; also engages in evaluating and trading second-hand rotary drilling rigs.
Xuzhou Reman Construction Machinery Remanufacture Co., Ltd has many year's technical advantages, professional and experienced maintenance team; with moving maintenance shop--special vehicle for rigs field service; and advanced testing equipment, professional repairing workshop, spare parts warehouse, perfect testing methods and management system, all of these ensure the quality of our service and woke efficiency.
Construction Cases
Certifications
Standard exporting packing, suitable for shipment.
Weclome to visit our website:reman.en.china.cn!
