WM303A Fully Auto Conveyorized Pallet Wrapper + Top Sheet Dispenser
US$ 1,000 - 5,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Other, Machinery & Hardware
Packaging Type:
Cartons
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
WM207CR Automatic Remote Controlled Wrapping With Top Sheet Dispensing MachineUS$ 1,000 - 5,000MOQ: 1 Set -
WM102 Semi-Auto Economical Pallet WrapperUS$ 1,000 - 5,000MOQ: 1 Set
-
WM205 Semi-Auto Pallet Wrapper Mechanical BrakeUS$ 1,000 - 5,000MOQ: 1 Set
-
Pallet Wrapping Machine WM101 Pre-Stretch Semi-AutoUS$ 2,500 - 5,000MOQ: 1 Unit
-
FBI Packing MachineUS$ 1,000 - 5,000MOQ: 1 Set
Condition
New
Application
Other, Machinery & Hardware
Packaging Type
Cartons
Packaging Material
Plastic
Automatic Grade
Automatic
Driven Type
Electric
Power
33PH380VAC, 50/60Hz, 20A, 3kw
Place of Origin
Guangdong, China
Brand Name
FBI
Model Number
WM303A
Specifications
1.long history wrapper manufacturerund price with excellent quality
3.mainly export to U.S & Euro
4.CE certificated
FBI Packing Co.,Ltd is specialized in manufacturing and exporting with wide range of stretch wrapping machines.
We are the world leading manufacturer of stretch wrapping machine.
We adopt PLC and frequency transducers control system for easy operation and reliable performance, requiring no maintenance.
Since establishment in 1994, FBI is making great progresses in the packing industry, with more expertise in the field of wrapping machine. Our products have been CE certificated with its reliable and stable quality.
Our experience and knowledge of packing machinery enable us to provide perfect solutions to meet specific packaging needs with different industries.
Don’t hesitate to contact us. Leave us a message and let’s find the solution.
| Features |
| WM303A is conveyorized wrappers for automated unmanned packing lines. Controlled by the same control system, pallets can be automatically wrapped and covered on the top simultaneously to be protected against dust & moisture, and achieve perfect exterior looking. This system has now been widely used to enhance work efficiency, reduce labor cost and raise packing grades, in industries such as chemicals, electric & electronic, food & beverage, paper making, etc. Top Sheet Dispenser could be ordered independently to go with present wrapper. |
| 1.Two working mode choices: wrapping, or wrapping with top sheet dispensing. |
| 2.Automatic stretch film apply & cut, pneumatically driven. |
| 3.Swing ring structure turntable for a quieter operating environment and increase reliability. |
| 4.Powered pre-stretch film carriage, ratio 250%. |
| 5.Automatic wrapping according to pre-set parameters. Friendly user interface for setting wrap cycles, top/bottom cycles & film tension. |
| 6.Auto film brushing unit fitted to make sure film clicking to the pallets perfectly after cutting. |
| Technical Specifications | ||||
| Turntable height | 456mm | |||
| Machine Weight | 1800kg | |||
| Top sheet size | Width 1700mm,length variable | |||
| Pallet sizes | 800-1200mm(L)×800-1200(W)×2100mm(H) | |||
| Maximum load weight | 2500kg | |||
| Throughput | 18-25pallet/hour | |||
| Rotation speed | 0-15 rpm,speed variable,turntable soft start&soft stop | |||
| Film carriage lift speed | 3m/min | |||
| Top dispensing unit lifting speed | 3m/min | |||
| Top sheet pulling speed | 12m/min | |||
| Controller | PLC | |||
| Working mode | fully auto | |||
| Power requirements | 3PH380VAC, 50/60Hz, 20A, 3kw | |||
| Air pressure | 0.4-0.7Mpa | |||
| Cutting Method | Heater | |||
