JD-4009 Brass/zinc Ball Valve/brass Factory
US$ 0.3 - 20
MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Standard or Nonstandard:
Standard
Structure:
Ball
Pressure:
Medium Pressure
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO OR SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Lead-free Brass Brass Ball Valve Full Flow Brass Ball Valve JD-4012US$ 0.2 - 20MOQ: 1000 Pieces -
JD-5010 Brass Pipe FittingUS$ 0.2 - 20MOQ: 1000 Pieces
-
JD-5007 Pipe FittingsUS$ 0.2 - 20MOQ: 1000 Pieces
-
JD-30085 Brass Stop ValveUS$ 1 - 30MOQ: 3000 Pieces
-
JD-4010 ( JD-4010 ) Lead-free Brass Full Pore Brass Ball Valve,US$ 0.2 - 20MOQ: 1000 Pieces
Standard or Nonstandard
Standard
Structure
Ball
Pressure
Medium Pressure
Power
Manual
Material
Brass
Temperature of Media
Medium Temperature
Media
Water
Port Size
20
Place of Origin
Taiwan, China
Model Number
JD-4009, JD-4009
Brand Name
JD toyo ITALY
BRASS BALL VALVE
- Body :Brass
- Ball:Brass
- Stem: Brass
- Handle :Steel handle with plastic cover .
- Size: 1/2 . 3/4 . 1 . 1 1/2 . 1 1/4 . 2 . 2 1/2 . 3 . 4
- Package: Standard export packaging .We will use stamdard export package if no special requirements . but it is availible to provide co.lourful package according to your design or we make design or your brand if required .
- Lead time : 30 days after getting your deposit or LC
size:1/4"-4"
| max pressure: 25 bar | |||||
| temp.:-10<t<120 | |||||
| threaded : ISO228/1:2000 | |||||
| opening /closing tests:20000times . | |||||
| anti-oxygen glue applied to join body&bonnet | |||||
| suitable medium: water &non-causticity liquid ,&saturated steam | |||||
NO. |
Component |
Material |
1 |
Body |
Brass |
2 |
Bonnet |
Brass |
3 |
Ball |
Brass |
4 |
Seat Ring |
Tefon |
5 |
Stem |
Brass |
6 |
Packing Rings |
Teflon PVC |
7 |
Washer |
Brass |
8 |
Handle |
steel |
9 |
Nut |
Iron |
material: brass body , brass ball, brass stem , steel handle .
BOTE BALL VALVE are bottom lkoaded stem designed , this anti blow out stem also prevent tampering with the internals of the valve when in the line , and the ball valve have a double seal with elastic O-ringS chosen for their high resistance to ageing . perfect seal at low and high pressure and wear resistant , solid and relianble for life time use.
