Help CenterRG58 59 6 Coaxial Cable Stripper
Related Products
Specifications
For RG 58/59/6Strip coaxial jacket and inner conductor
No replacement of cassette
No adjustment for V-Block
RG58 59 6 Coaxial Cable Stripper
Instructions
♦ Stripping Length: This stripper can strip cable in two lengths 10 and 12mm.
322 and 322S3 stripping length is preset to 12mm (3 blades model). 322S is preset to 8mm (2 blades model). If you want to strip other lengths, you may adjust the blade's position.
♦ Blades' Depth: You may use the hex wrench, which is install on the bottom of the tool to adjust the blades' depth.Insert the hex wrench into the blade depth adjuster on the bottom of the stripper, then rotate the hex wrench clockwise (to cut smaller cable) or counterclockwise (to cut larger cable).
Repeat above steps to set the other blade.
♦ Stripping Cable:
1.The stripper is designed for stripping cables without any adjustment of V-block.
2.Press the knurled portion on the upper jaw to open the stripper's jaws.
3.Insert the cable you want to strip through the V-block until the cable reaches the V-shaped cable guide. Then release the upper jaw to close the jaws.
4.Insert your index finger into the stripper's finger ring, turn the stripper clockwise 3-5 times. The cable's insulation is cut while you turn the stripper.
5.Open the jaws and remove the cable. Pull away the outer jacket and dielectric to expose the inner conductor
