Ultrasound Machine , Color Doppler Ultrasound Machine, Ultrasound Scanner
Imaging Processing
Pre-processing :
1 Cloud processing technology
2 Fine blood flow imaging, high sensitive
3 Gain
4 8-segment TGC
5 Dynamic range
6 Persistence
7 M soften
Post-processing:
1 Image enhancement
2 Gray-scale map
3 Pseudo color map
4 Interface to turn 180°
5 Left/right reverse
6 Up/down reverse
Application Package
Abdominal,Obstetrics,Gynecology, Urinary System, Cardiology, Radiology, and Organs/Small parts, Musculoskeletal, Pediatrics and Vascular, etc.
Function
Smart touch- screen design: |
Supported |
Cine loop: |
334 frames movie playback stored |
Amplification: |
10 times |
Qopt: |
One-key optimize |
Multi language: |
Supported |
DICOM: |
Supported |
Print: |
Report print for text&graph&image |
Technical Specification
Modes: |
B,M,2B,B/M,4B,C,PW, Power,DirPower,THI |
Gray Level: |
256 |
Display: |
15”LCD monitor |
Touchscreen: |
Full Touchscreen |
Transducer Frequency: |
2-11Mhz |
Digital Technology: |
Wide-angle imaging |
Panoramic focusing technology | |
Compatible with high and low speed blood | |
Panoramic imaging | |
Frequency composite | |
Space compound | |
Rolling M technology | |
Real-time Dynamic Aperture | |
Tissue Harmonic Imaging | |
Scanning Depth: |
220mm |
Probe ports: |
3 active transducer connector ports |
Peripheral ports: |
2 USB ports, serial port, LAN Ethernet, S-video |
Power supply: |
100-240V~ 50/60Hz <100VA |
Measurement and Calculation
B mode: |
Distance, angle, area, volume, trace length, length ratio, area ratio,histogram |
M mode: |
Distance, time, slope, heart rate |
Color and PW mode: |
D velocity, D trace, PS/ED |
Application package: |
Abdomen, Obstetric, Gynecology, Cardiac, Neural and Small parts. |
Standard Configuration
Main unit
15 inch high resolution LCD display:1024*768
Touchscreen
Two USB ports
One s-video out port
One networking port
One power inlet
3.5 MHz Large convex probe
Three transducer connectors
Abundant measurement&calculation software package.
Main unit warranty time 18 months
Probe warranty time 12 months
Probe Option (support 2~14MHz wideband probe,80 and 128elements)
Packing: bag &carton.
Shipping: DHL, TNT, UPS, Fedex, ARAMEX, etc
Introduction of Each Unit
No. |
Name |
Function |
1 |
Touch screen display |
Displays the images and parameters during scanning. |
2 |
Control Panel |
Operator-system interface or control. |
3 |
Probe Cup |
Place the probes |
4 |
Handle |
Used for carrying the system. |
5 |
Probe port |
Connects a probe to the main unit; or connects a probe extend module. |
6 |
Serial interface |
Universal serial port. |
7 |
S-Video separate video output |
Connects video printer. |
8 |
Network port |
Connects the network. |
9 |
USB port |
Connects the USB devices |
