Specifications
simplex hybrid SC-ST fiber adapter1.free sample available
2.welcome OEM/ODM
3.100% Optical test
4.ST/SC/FC/LC
SC-ST fiber adapter
Features:
Low insertion loss, high return loss
Good compatibility
High precision of mechanical dimensions
High reliability & stability
Ceramic or Bronze Sleeve
PC,APC,UPC optional
Simplex / Duplex / Quad
Application:
Local Area Network
CATV System
Telecommunication Networks
Equipment Test
specification:
Insertion loss |
Singlemode |
PC≤0.3dB |
UPC≤0.2dB |
APC ≤0.3dB |
Multimode |
PC≤0.5dB |
UPC≤0.3dB |
APC ≤0.3dB |
|
Return loss |
Singlemode |
PC≥48dB |
UPC≥50dB |
APC ≥60dB |
Multimode |
PC≥25dB |
UPC≥45dB |
APC ≥50dB |
|
Reaptability |
≤0.1db |
|||
Changeability |
≤0.2dB |
|||
Working temperature |
-40 to +80degree |
|||
Durability |
1000 times |
|||
Sustain tension |
≥100N |
|||
Fiber |
9/125um ,50/125um, 62.5/125um , etc. |
|||
Diameter |
0.9mm 2.0mm 3.0mm , etc. |
|||
Cable material |
PVC, LSZH |
|||
Cores |
Simplex, duplex, 4cores, 6cores, 8cores,12cores, etc. |
|||
