Help CenterRight Angle Connector Sma Pcb Connector
Related Products
Specifications
right angle connector sma pcb connector1,material: copper or zinc
2,plating: gold/nickel/tin
3,high quality (ROHS)
SMA Female Right Angle RF connector
Type SMA is one kind of RF coaxial connectors that is widely applied, with small-sized thread coupling characteristic. Impedance is 50Ω. The characteristic of connectors is in wide frequency range,excellent performance,high reliability. They are used in connection with RF cable or micro-strip line in RF circuit of the WLAN system,controlled program,microwave equipment and digital communication system. The frequency can be up to 18GHz by using semi-rigid or semi-flex cable.
Electronical Specifications
|
Impedance
|
50Ω |
|
Frequency Range |
0-12.4 GHz on Flexible cable 0-18 GHz on Semi-rigid cable |
|
Working Voltage |
RG-316, .085": 250 VRMS max. at sea level RG-178: 170 VRMS max. at sea level |
|
Dielectric Withstanding Voltage |
RG-178: 500 VRMS max. at sea level RG-316, .085": 750 VRMS max. at sea level |
|
VSWR |
Straight: 1.3 max., R/A: 1.5 max |
|
Contact Resistance
|
Center Contact: 6 milliohm Max Outer Contact: 2 milliohm Max |
|
Insulator Resistance
|
5000 megaohms min1 |
MOQ : 500Pcs
Pckaging style: Neutral or customized packing accepted
Payment terms: We accept Paypal,T/T, Western Union ,L/C
Delivery time: 5-7 working days after payment
Shipment:
1. The parts from us are sure to have quality warranty,and they are double tested before shipping.
2. The items can be sent within 5 working day after the payment reaches us,except for mass process, we will confirm the delivery in advance.
3. We can send your order by UPS/DHL/TNT/ FedEx. Pls contact us directly and we will use your preferred ways.
4. Any import fees or charges are the buyer's responsibility. But we can help you reduce and avoid import taxes by declaring prices low, declaring the contents as "electronic accessories" or other items and shipping in simple packaging.
