Home > Products > Series mini circuit breakers > dz30 china circuit breaker 230v
dz30 china circuit breaker 230v
USD $0.46 - $1.59
/ Piece
1 Piece(Min.Order)
- 50000 Piece / Pieces per Month
- Shanghai Ningbo
- T/T Credit Card
You May Like
Product Details
Place of Origin: | Zhejiang, China | Brand Name: | Suoneng | Model Number: | DZ30 |
Type: | Mini | Poles Number: | Other, 1P+N |
Product Description
Circuit breaker 16a best mcb rccb circuit breaker
Application range
1. DZ30 series mini circuit breaker is applied in the circuit of AC50HZ,rated voltage 230V, rated current 32A.
2. It is uesly used in industrial and commercial lighting .
Main technical parameter
Rated current (A) | pole | rated voltage (V) | rated current of flame (A) | rated breaking capacity of shodclrcuit | mechanical life | rated leakage action current(MA) | ratedleakagenon-action current(MA) | Breakingtime(s) |
3,6,10,16, 20,25,32 | 1P+N | 230V | 32 | 3000,4500,6000 | 20000 | 30 | 15 | <0.1S |
Over-current protective characteristic
Trial | Instantuneous release type | rated values |
Trial current | Tripping and nontripping time uttimate | prospective result | note |
a | C,D | all the values | 1.13In | t<1h | no tripping | cold state |
all the values | ||||||
b | C,D | all the values | 1.45In | t<1h | tripping | follow with No.atrial |
all the values | ||||||
c | C,D | In<32A | 2.55In | 1s<t<60s | tripping | cold state |
32A<In<63A | 1s<t<120s | |||||
d | C,D | all the values | 5In | t<0.1s | no tripping | cold state |
all the values | 10In | |||||
e | C,D | all the values | 10In | t<0.1s | tripping | cold state |
all the values | 20In |
